5UJP | pdb_00005ujp

The crystal structure of a glyoxalase/bleomycin resistance protein from Streptomyces sp. CB03234

• PDB DOI: https://doi.org/10.2210/pdb5UJP/pdb

• Classification: LYASE
• Organism(s): Streptomyces sp. CB03234
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2017-01-18 Released: 2017-02-22
• Deposition Author(s): Tan, K., Li, H., Endres, M., Phillips Jr., G.N., Joachimiak, A., Midwest Center for Structural Genomics (MCSG), Enzyme Discovery for Natural Product Biosynthesis (NatPro)
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.42 Å
• R-Value Free:
  0.202 (Depositor), 0.203 (DCC)
• R-Value Work:
  0.161 (Depositor), 0.162 (DCC)
• R-Value Observed:
  0.163 (Depositor)

Literature

The crystal structure of a glyoxalase/bleomycin resistance protein from Streptomyces sp. CB03234

Tan, K., Li, H., Endres, M., Phillips Jr., G.N., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 25.18 kDa
• Atom Count: 1,921
• Modeled Residue Count: 228
• Deposited Residue Count: 228
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glyoxalase/bleomycin resisance protein/dioxygenase	A, B	114	Streptomyces sp. CB03234	Mutation(s): 0  Gene Names: tnmS3
UniProt
Find proteins for A0A125SA29 (Streptomyces sp. (strain CB03234)) Explore A0A125SA29  Go to UniProtKB:  A0A125SA29

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MES	D [auth B]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C6 H13 N O4 S SXGZJKUKBWWHRA-UHFFFAOYSA-N
CA	C [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.42 Å
• R-Value Free:  0.202 (Depositor), 0.203 (DCC)
• R-Value Work:  0.161 (Depositor), 0.162 (DCC)
• R-Value Observed: 0.163 (Depositor)

Space Group: P 3₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.352	α = 90
b = 55.352	β = 90
c = 62.982	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2017-02-22
Deposition Author(s): Tan, K., Li, H., Endres, M., Phillips Jr., G.N., Joachimiak, A., Midwest Center for Structural Genomics (MCSG), Enzyme Discovery for Natural Product Biosynthesis (NatPro)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM115586

Revision History

• Version 1.0: 2017-02-22
  Type: Initial release

• Version 1.1: 2017-09-20
  Changes: Author supporting evidence
• Version 1.2: 2020-01-01
  Changes: Author supporting evidence
• Version 1.3: 2024-11-13
  Changes: Data collection, Database references, Derived calculations, Structure summary
