5U6Z | pdb_00005u6z

Crystal Structure of Xenopus laevis Apex2 C-terminal Znf-GRF Domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:
    0.245 (Depositor), 0.259 (DCC)
  • R-Value Work:
    0.195 (Depositor), 0.204 (DCC)
  • R-Value Observed:
    0.200 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5U6Z

This is version 1.2 of the entry. See complete history

Literature

APE2 Zf-GRF facilitates 3'-5' resection of DNA damage following oxidative stress.

Wallace, B.D.Berman, Z.Mueller, G.A.Lin, Y.Chang, T.Andres, S.N.Wojtaszek, J.L.DeRose, E.F.Appel, C.D.London, R.E.Yan, S.Williams, R.S.

(2017) Proc Natl Acad Sci U S A 114: 304-309

  • DOI: https://doi.org/10.1073/pnas.1610011114
  • Primary Citation Related Structures:
    5U6Z

  • PubMed Abstract:

    The Xenopus laevis APE2 (apurinic/apyrimidinic endonuclease 2) nuclease participates in 3'-5' nucleolytic resection of oxidative DNA damage and activation of the ATR-Chk1 DNA damage response (DDR) pathway via ill-defined mechanisms. Here we report that APE2 resection activity is regulated by DNA interactions in its Zf-GRF domain, a region sharing high homology with DDR proteins Topoisomerase 3α (TOP3α) and NEIL3 (Nei-like DNA glycosylase 3), as well as transcription and RNA regulatory proteins, such as TTF2 (transcription termination factor 2), TFIIS, and RPB9. Biochemical and NMR results establish the nucleic acid-binding activity of the Zf-GRF domain. Moreover, an APE2 Zf-GRF X-ray structure and small-angle X-ray scattering analyses show that the Zf-GRF fold is typified by a crescent-shaped ssDNA binding claw that is flexibly appended to an APE2 endonuclease/exonuclease/phosphatase (EEP) catalytic core. Structure-guided Zf-GRF mutations impact APE2 DNA binding and 3'-5' exonuclease processing, and also prevent efficient APE2-dependent RPA recruitment to damaged chromatin and activation of the ATR-Chk1 DDR pathway in response to oxidative stress in Xenopus egg extracts. Collectively, our data unveil the APE2 Zf-GRF domain as a nucleic acid interaction module in the regulation of a key single-strand break resection function of APE2, and also reveal topologic similarity of the Zf-GRF to the zinc ribbon domains of TFIIS and RPB9.


  • Organizational Affiliation
    • Genome Integrity and Structural Biology Laboratory, National Institute of Environmental Health Sciences, National Institutes of Health, Department of Health and Human Services, Research Triangle Park, NC 27709.

Macromolecule Content

  • Total Structure Weight: 8.43 kDa
  • Atom Count: 543
  • Modeled Residue Count: 67
  • Deposited Residue Count: 75
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-(apurinic or apyrimidinic site) lyase75Xenopus laevisMutation(s): 0
Gene Names: apex2apex2-prov
EC: 4.2.99.18 (PDB Primary Data), 3.1.11.2 (UniProt)
UniProt
Find proteins for Q6DDT4 (Xenopus laevis)
Explore Q6DDT4
Go to UniProtKB:  Q6DDT4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6DDT4
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:  0.245 (Depositor), 0.259 (DCC)
  • R-Value Work:  0.195 (Depositor), 0.204 (DCC)
  • R-Value Observed: 0.200 (Depositor)
Space Group: I 4
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.332α = 90
b = 90.332β = 90
c = 23.105γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-3000data reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-01-11
    Type: Initial release
  • Version 1.1: 2017-01-25
    Changes: Database references
  • Version 1.2: 2024-03-06
    Changes: Data collection, Database references
