5TKO | pdb_00005tko

RNA heptamer duplex with one 2'-5'-linkage

• PDB DOI: https://doi.org/10.2210/pdb5TKO/pdb
• NAKB: 5TKO

• Classification: RNA
• Organism(s): unidentified
• Mutation(s): No


• Deposited: 2016-10-07 Released: 2017-10-11
• Deposition Author(s): Luo, Z., Sheng, J.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.52 Å
• R-Value Free:
  0.177 (Depositor), 0.184 (DCC)
• R-Value Work:
  0.144 (Depositor), 0.152 (DCC)
• R-Value Observed:
  0.147 (Depositor)

Starting Model: experimental

Literature

RNA heptamer duplex with one 2'-5'-linkage

Luo, Z., Sheng, J., Wang, R.

To be published.

Biological Assembly 1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 8.89 kDa
• Atom Count: 672
• Modeled Residue Count: 28
• Deposited Residue Count: 28
• Unique nucleic acid chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Length	Organism	Image
RNA (5'-R(*UP*AP*GP*CP*UP*CP*C)-3')	A, C	7	unidentified

Entity ID: 2
Molecule	Chains	Length	Organism	Image
RNA (5'-R(*GP*GP*AP*GP*CP*UP*A)-3')	B, D	7	unidentified

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CO	E [auth A]	COBALT (II) ION Co XLJKHNWPARRRJB-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.52 Å
• R-Value Free:  0.177 (Depositor), 0.184 (DCC)
• R-Value Work:  0.144 (Depositor), 0.152 (DCC)
• R-Value Observed: 0.147 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 26.541	α = 90
b = 52.941	β = 95.95
c = 27.732	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2017-10-11
Deposition Author(s): Luo, Z., Sheng, J.

Revision History

• Version 1.0: 2017-10-11
  Type: Initial release

• Version 1.1: 2023-10-04
  Changes: Data collection, Database references, Derived calculations, Refinement description
