5T8N | pdb_00005t8n

Crystal structure of Snf7 under 200 MPa

• PDB DOI: https://doi.org/10.2210/pdb5T8N/pdb

• Classification: PROTEIN TRANSPORT
• Organism(s): Saccharomyces cerevisiae S288C
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2016-09-07 Released: 2017-08-16
• Deposition Author(s): Huang, Q., Szebenyi, D.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:
  0.345 (Depositor), 0.345 (DCC)
• R-Value Work:
  0.242 (Depositor), 0.245 (DCC)
• R-Value Observed:
  0.253 (Depositor)

Starting Model: experimental

Literature

Crystal structure of Snf7 under 200 MPa

Huang, Q., Szebenyi, D.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 15.8 kDa
• Atom Count: 1,005
• Modeled Residue Count: 125
• Deposited Residue Count: 139
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Vacuolar-sorting protein SNF7	A	139	Saccharomyces cerevisiae S288C	Mutation(s): 0  Gene Names: SNF7, DID1, VPS32, YLR025W
UniProt
Find proteins for P39929 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore P39929  Go to UniProtKB:  P39929

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:  0.345 (Depositor), 0.345 (DCC)
• R-Value Work:  0.242 (Depositor), 0.245 (DCC)
• R-Value Observed: 0.253 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 29.826	α = 90
b = 47.844	β = 98.87
c = 45.185	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHENIX	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2017-08-16
Deposition Author(s): Huang, Q., Szebenyi, D.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM-103485

Revision History

• Version 1.0: 2017-08-16
  Type: Initial release

• Version 1.1: 2019-12-25
  Changes: Author supporting evidence
• Version 1.2: 2023-10-04
  Changes: Data collection, Database references, Refinement description
