5T0W | pdb_00005t0w

Crystal structure of the ancestral amino acid-binding protein AncCDT-1, a precursor of cyclohexadienyl dehydratase

PDB DOI: https://doi.org/10.2210/pdb5T0W/pdb

Classification: TRANSPORT PROTEIN
Organism(s): synthetic construct
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2016-08-16 Released: 2017-09-06
Deposition Author(s): Clifton, B.E., Carr, P.D., Jackson, C.J.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.59 Å
R-Value Free:
0.287 (Depositor), 0.269 (DCC)
R-Value Work:
0.253 (Depositor)
R-Value Observed:
0.255 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5T0W

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

To be published

Clifton, B.E., Kaczmarski, J.A., Carr, P.D., Jackson, C.J.

To be published.

Macromolecule Content

Total Structure Weight: 111.82 kDa
Atom Count: 7,011
Modeled Residue Count: 910
Deposited Residue Count: 988
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
AncCDT-1	A, B, C, D	247	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ARG Query on ARG Download:Ideal Coordinates CCD File SDF format, chain H [auth D] SDF format, chain G [auth C] SDF format, chain F [auth B] SDF format, chain E [auth A] MOL2 format, chain H [auth D] MOL2 format, chain G [auth C] MOL2 format, chain F [auth B] MOL2 format, chain E [auth A] mmCIF format, chain H [auth D] mmCIF format, chain G [auth C] mmCIF format, chain F [auth B] mmCIF format, chain E [auth A]	E [auth A], F [auth B], G [auth C], H [auth D]	ARGININE C₆ H₁₅ N₄ O₂ ODKSFYDXXFIFQN-BYPYZUCNSA-O		Interactions Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.59 Å
R-Value Free: 0.287 (Depositor), 0.269 (DCC)
R-Value Work: 0.253 (Depositor)
R-Value Observed: 0.255 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 47.03	α = 90
b = 68.88	β = 90
c = 318.63	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
iMOSFLM	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-09-06

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2017-09-06
Type: Initial release
Version 1.1: 2017-11-01
Changes: Author supporting evidence
Version 1.2: 2023-10-04
Changes: Data collection, Database references, Refinement description
