Crystal Structure of a human phosphodiesterase 10 complex
Flohr, A., Schlatter, D., Kuhn, B., Rudolph, M.G.To be published.
Experimental Data Snapshot
Starting Model: other
View more details
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
cAMP and cAMP-inhibited cGMP 3',5'-cyclic phosphodiesterase 10A | 343 | Homo sapiens | Mutation(s): 0  Gene Names: PDE10A EC: 3.1.4.17 | ||
UniProt & NIH Common Fund Data Resources | |||||
Find proteins for Q9Y233 (Homo sapiens) Go to UniProtKB:  Q9Y233 | |||||
PHAROS:  Q9Y233 GTEx:  ENSG00000112541  | |||||
Sequence AnnotationsExpand | |||||
|
Ligands 4 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
KI8 (Subject of Investigation/LOI) Query on KI8 | G [auth A], K [auth B], N [auth C], Q [auth D] | [4-(2-methoxyphenyl)piperazin-1-yl](3-methyl-1-phenyl-1H-thieno[2,3-c]pyrazol-5-yl)methanone C24 H24 N4 O2 S BWFNMEVYLTWLDQ-UHFFFAOYSA-N | |||
GOL Query on GOL | J [auth B] | GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N | |||
ZN Query on ZN | E [auth A], H [auth B], L [auth C], O [auth D] | ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N | |||
MG Query on MG | F [auth A], I [auth B], M [auth C], P [auth D] | MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N |
Modified Residues 1 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Type | Formula | 2D Diagram | Parent |
CME Query on CME | A, B, C, D | L-PEPTIDE LINKING | C5 H11 N O3 S2 | CYS |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 135.91 | α = 90 |
b = 135.91 | β = 90 |
c = 236.75 | γ = 120 |
Software Name | Purpose |
---|---|
XSCALE | data scaling |
REFMAC | refinement |
PDB_EXTRACT | data extraction |
XDS | data reduction |
XSCALE | data scaling |
PHASER | phasing |
Funding Organization | Location | Grant Number |
---|---|---|
F. Hoffmann-La Roche | Switzerland | -- |
