5SCT

Crystal Structure of Dihydrofolate Reductase from Mycobacterium tuberculosis bound to NADP and SDDC Inhibitor SDDC-783

PDB DOI: https://doi.org/10.2210/pdb5SCT/pdb
Deposition Group: G_1002223 (ground state) ExploreG_1002223

Classification: OXIDOREDUCTASE/OXIDOREDUCTASE INHIBITOR
Organism(s): Mycobacterium tuberculosis H37Rv
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-12-20 Released: 2022-02-09
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free: 0.181
R-Value Work: 0.155
R-Value Observed: 0.157

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of Dihydrofolate Reductase from Mycobacterium tuberculosis bound to NADP and SDDC Inhibitor SDDC-783

Mayclin, S.J., Fairman, J.W., Dranow, D.M., Conrady, D.G., Fox III, D., Lukacs, C.M., Lorimer, D.D., Horanyi, P.S., Edwards, T.E., Abendroth, J.

To be published.

Macromolecule Content

Total Structure Weight: 21.04 kDa
Atom Count: 1,616
Modelled Residue Count: 173
Deposited Residue Count: 179
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Dihydrofolate reductase	A	179	Mycobacterium tuberculosis H37Rv	Mutation(s): 0 Gene Names: folA, dfrA, Rv2763c, MTV002.28c EC: 1.5.1.3
UniProt
Find proteins for P9WNX1 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WNX1 Go to UniProtKB: P9WNX1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P9WNX1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAP Query on NAP Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C₂₁ H₂₈ N₇ O₁₇ P₃ XJLXINKUBYWONI-NNYOXOHSSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
H03 (Subject of Investigation/LOI) Query on H03 Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	3-(2-{3-[(2,4-diamino-6-ethylpyrimidin-5-yl)oxy]propoxy}phenyl)-N-(dimethylsulfamoyl)propanamide C₂₀ H₃₀ N₆ O₅ S BPOQBXWDCPLQOH-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free: 0.181
R-Value Work: 0.155
R-Value Observed: 0.157
Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 29.19	α = 90
b = 67.17	β = 90
c = 72.45	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
PHENIX	model building
Coot	model building
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2022-02-09

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700059C

Revision History (Full details and data files)

Version 1.0: 2022-02-09
Type: Initial release
Version 1.1: 2022-03-02
Changes: Other, Structure summary
Version 1.2: 2024-05-22
Changes: Data collection
