5QTN | pdb_00005qtn

PanDDA analysis group deposition -- Crystal Structure of NUDT5 in complex with SS-4432

PDB DOI: https://doi.org/10.2210/pdb5QTN/pdb
Deposition Group: G_1002105 (changed state) | Explore G_1002105

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2019-08-14 Released: 2019-12-25
Deposition Author(s): Dubianok, Y., Krojer, T., Kovacs, H., Moriaud, F., Wright, N., Strain-Damerell, C., Burgess-Brown, N., Bountra, C., Arrowsmith, C.H., Edwards, A., von Delft, F.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.83 Å
R-Value Free:
0.275 (Depositor), 0.284 (DCC)
R-Value Work:
0.238 (Depositor), 0.253 (DCC)
R-Value Observed:
0.240 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

PanDDA analysis group deposition

Dubianok, Y., Krojer, T., Kovacs, H., Moriaud, F., Wright, N., Strain-Damerell, C., Burgess-Brown, N., Bountra, C., Arrowsmith, C.H., Edwards, A., von Delft, F.

To be published.

Macromolecule Content

Total Structure Weight: 93.37 kDa
Atom Count: 6,070
Modeled Residue Count: 775
Deposited Residue Count: 836
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ADP-sugar pyrophosphatase	A, B, C, D	209	Homo sapiens	Mutation(s): 0 Gene Names: NUDT5, NUDIX5, HSPC115 EC: 3.6.1.13 (PDB Primary Data), 3.6.1.58 (PDB Primary Data), 2.7.7.96 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UKK9 (Homo sapiens) Explore Q9UKK9 Go to UniProtKB: Q9UKK9
PHAROS: Q9UKK9 GTEx: ENSG00000165609
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9UKK9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PWD Query on PWD Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain M [auth B] SDF format, chain Q [auth C] MOL2 format, chain H [auth A] MOL2 format, chain M [auth B] MOL2 format, chain Q [auth C] mmCIF format, chain H [auth A] mmCIF format, chain M [auth B] mmCIF format, chain Q [auth C]	H [auth A], M [auth B], Q [auth C]	5-fluoro-1H-pyrrolo[2,3-b]pyridine C₇ H₅ F N₂ BALBNSFYMXBWNM-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain M [auth B] Focus chain Q [auth C] Interactions & Density Focus chain H [auth A] Focus chain M [auth B] Focus chain Q [auth C]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth B] SDF format, chain N [auth C] MOL2 format, chain I [auth A] MOL2 format, chain J [auth B] MOL2 format, chain N [auth C] mmCIF format, chain I [auth A] mmCIF format, chain J [auth B] mmCIF format, chain N [auth C]	I [auth A], J [auth B], N [auth C]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth B] Focus chain N [auth C] Interactions & Density Focus chain I [auth A] Focus chain J [auth B] Focus chain N [auth C]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain O [auth C] SDF format, chain P [auth C] SDF format, chain R [auth D] SDF format, chain S [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain O [auth C] MOL2 format, chain P [auth C] MOL2 format, chain R [auth D] MOL2 format, chain S [auth D] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain O [auth C] mmCIF format, chain P [auth C] mmCIF format, chain R [auth D] mmCIF format, chain S [auth D]	E [auth A] F [auth A] K [auth B] L [auth B] O [auth C] E [auth A], F [auth A], K [auth B], L [auth B], O [auth C], P [auth C], R [auth D], S [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain O [auth C] Focus chain P [auth C] Focus chain R [auth D] Focus chain S [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain O [auth C] Focus chain P [auth C] Focus chain R [auth D] Focus chain S [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.83 Å
R-Value Free: 0.275 (Depositor), 0.284 (DCC)
R-Value Work: 0.238 (Depositor), 0.253 (DCC)
R-Value Observed: 0.240 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.083	α = 79.55
b = 59.814	β = 81.29
c = 79.586	γ = 75.78

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
REFMAC	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2019-12-25

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2019-12-25
Type: Initial release
Version 1.1: 2024-03-06
Changes: Data collection, Database references, Derived calculations
Version 1.2: 2024-10-30
Changes: Structure summary
Version 1.3: 2026-02-18
Changes: Refinement description
