5Q08 | pdb_00005q08

Human liver fructose-1,6-bisphosphatase 1 (fructose 1,6-bisphosphate 1-phosphatase, E.C.3.1.3.11) complexed with the allosteric inhibitor 1-(1-benzothiophen-3-ylsulfonyl)-3-(5-bromo-1,3-thiazol-2-yl)urea

• PDB DOI: https://doi.org/10.2210/pdb5Q08/pdb
• Deposition Group: G_1002030 | Explore  G_1002030

• Classification: HYDROLASE/HYDROLASE INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2017-04-18 Released: 2019-01-09
• Deposition Author(s): Ruf, A., Joseph, C., Alker, A., Banner, D., Tetaz, T., Benz, J., Kuhn, B., Rudolph, M.G., Yang, H., Shao, C., Burley, S.K.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:
  0.204 (Depositor), 0.205 (DCC)
• R-Value Work:
  0.158 (Depositor), 0.158 (DCC)
• R-Value Observed:
  0.160 (Depositor)

Literature

Human liver fructose-1,6-bisphosphatase 1 (fructose 1,6-bisphosphate 1-phosphatase, E.C.3.1.3.11) complexed with the allosteric inhibitor 1-(1-benzothiophen-3-ylsulfonyl)-3-(5-bromo-1,3-thiazol-2-yl)urea

Ruf, A., Joseph, C., Alker, A., Banner, D., Tetaz, T., Benz, J., Kuhn, B., Rudolph, M.G.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 298.22 kDa
• Atom Count: 21,011
• Modeled Residue Count: 2,542
• Deposited Residue Count: 2,704
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fructose-1,6-bisphosphatase 1	A, B, C, D, E, F, G, H	338	Homo sapiens	Mutation(s): 0  Gene Names: FBP1, hCG_1640493 EC: 3.1.3.11
UniProt & NIH Common Fund Data Resources
Find proteins for P09467 (Homo sapiens) Explore P09467  Go to UniProtKB:  P09467
PHAROS:  P09467 GTEx:  ENSG00000165140

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
967	I [auth A], J [auth B], K [auth C], L [auth D], M [auth E], N [auth F], O [auth G], P [auth H]	N-[(5-bromo-1,3-thiazol-2-yl)carbamoyl]-1-benzothiophene-3-sulfonamide C12 H8 Br N3 O3 S3 YVUPAWIDSNSGIT-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:  0.204 (Depositor), 0.205 (DCC)
• R-Value Work:  0.158 (Depositor), 0.158 (DCC)
• R-Value Observed: 0.160 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.22	α = 90
b = 285.134	β = 97.57
c = 83.359	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-01-09
Deposition Author(s): Ruf, A., Joseph, C., Alker, A., Banner, D., Tetaz, T., Benz, J., Kuhn, B., Rudolph, M.G., Yang, H., Shao, C., Burley, S.K.

Revision History

• Version 1.0: 2019-01-09
  Type: Initial release

• Version 1.1: 2019-01-16
  Changes: Data collection
• Version 1.2: 2019-02-06
  Changes: Data collection, Database references, Structure summary
• Version 1.3: 2021-02-10
  Changes: Structure summary
• Version 1.4: 2024-03-06
  Changes: Data collection, Database references, Refinement description
