5ODN | pdb_00005odn

Salinibacter ruber Single-Strand Binding protein

PDB DOI: https://doi.org/10.2210/pdb5ODN/pdb
NAKB: 5ODN

Classification: DNA BINDING PROTEIN
Organism(s): Salinibacter ruber DSM 13855, Salinibacter ruber
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-07-06 Released: 2018-08-01
Deposition Author(s): Pierechod, M., Rothweiler, U.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free:
0.243 (Depositor), 0.245 (DCC)
R-Value Work:
0.190 (Depositor), 0.193 (DCC)
R-Value Observed:
0.192 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5ODN

This is version 1.3 of the entry. See complete history.

Literature

Salinibacter ruber Single-Strand Binding protein

Pierechod, M., Rothweiler, U.

To be published.

Macromolecule Content

Total Structure Weight: 183.98 kDa
Atom Count: 7,084
Modeled Residue Count: 854
Deposited Residue Count: 1,598
Unique protein chains: 1
Unique nucleic acid chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Single-stranded DNA-binding protein	A, B, C, D, E A, B, C, D, E, F, G, H	196	Salinibacter ruber DSM 13855	Mutation(s): 0 Gene Names: ssb, SRU_0523
UniProt
Find proteins for Q2S565 (Salinibacter ruber (strain DSM 13855 / M31)) Explore Q2S565 Go to UniProtKB: Q2S565
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q2S565
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 2
DNA (5'-D(PTPTPTPT)-3')	I J [auth M] K [auth J] L [auth K] M [auth N] I, J [auth M], K [auth J], L [auth K], M [auth N], O [auth Q]	4	Salinibacter ruber
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 3
DNA (5'-D(TPTP*T)-3')	N [auth P], P [auth L]	3	Salinibacter ruber
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.243 (Depositor), 0.245 (DCC)
R-Value Work: 0.190 (Depositor), 0.193 (DCC)
R-Value Observed: 0.192 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 106.47	α = 90
b = 123.5	β = 90
c = 205.25	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2018-08-01

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2018-08-01
Type: Initial release
Version 1.1: 2020-12-23
Changes: Database references
Version 1.2: 2021-02-03
Changes: Database references
Version 1.3: 2024-01-17
Changes: Data collection, Database references, Refinement description
