5OA9

Human translation re-initiation complex containing eIF2D


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.190
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structural and Functional Insights into Human Re-initiation Complexes.

Weisser, M.Schafer, T.Leibundgut, M.Bohringer, D.Aylett, C.H.S.Ban, N.

(2017) Mol Cell 67: 447-456.e7

  • DOI: https://doi.org/10.1016/j.molcel.2017.06.032
  • Primary Citation of Related Structures:
    5OA3, 5OA9

  • PubMed Abstract:

    After having translated short upstream open reading frames, ribosomes can re-initiate translation on the same mRNA. This process, referred to as re-initiation, controls the translation of a large fraction of mammalian cellular mRNAs, many of which are important in cancer. Key ribosomal binding proteins involved in re-initiation are the eukaryotic translation initiation factor 2D (eIF2D) or the homologous complex of MCT-1/DENR. We determined the structures of these factors bound to the human 40S ribosomal subunit in complex with initiator tRNA positioned on an mRNA start codon in the P-site using a combination of cryoelectron microscopy and X-ray crystallography. The structures, supported by biochemical experiments, reveal how eIF2D emulates the function of several canonical translation initiation factors by using three independent, flexibly connected RNA binding domains to simultaneously monitor codon-anticodon interactions in the ribosomal P-site and position the initiator tRNA.


  • Organizational Affiliation

    Department of Biology, Institute of Molecular Biology and Biophysics, Otto-Stern-Weg 5, ETH Zurich, CH-8093 Zurich, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Eukaryotic translation initiation factor 2D208Homo sapiensMutation(s): 0
Gene Names: EIF2DHCA56LGTN
UniProt & NIH Common Fund Data Resources
Find proteins for P41214 (Homo sapiens)
Explore P41214
Go to UniProtKB:  P41214
PHAROS:  P41214
GTEx:  ENSG00000143486
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP41214
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.190
  • R-Value Observed: 0.193
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50.72α = 90
b = 50.72β = 90
c = 197.39γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-07-26
    Type: Initial release
  • Version 1.1: 2017-08-09
    Changes: Database references
  • Version 1.2: 2017-08-16
    Changes: Database references
  • Version 1.3: 2024-05-08
    Changes: Data collection, Database references
