5O1V | pdb_00005o1v

Crystal structure of WNK3 kinase domain in a monophosphorylated apo state (A-loop swapped)

PDB DOI: https://doi.org/10.2210/pdb5O1V/pdb

Classification: STRUCTURAL GENOMICS
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2017-05-19 Released: 2017-06-28
Deposition Author(s): Pinkas, D.M., Bufton, J.C., Kupinska, K., Wang, D., Fairhead, M., Kopec, J., Sethi, R., Dixon-Clarke, S.E., Chalk, R., Berridge, G., Burgess-Brown, N.A., von Delft, F., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Bullock, A., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.72 Å
R-Value Free:
0.208 (Depositor), 0.210 (DCC)
R-Value Work:
0.173 (Depositor), 0.170 (DCC)
R-Value Observed:
0.175 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of WNK3 kinase domain in a monophosphorylated apo state (A-loop swapped)

Pinkas, D.M., Daubner, G.M., Bufton, J.C., Bartual, S.G., Sanvitale, C.E., Alessi, D.R., Bullock, A.

To be published.

Macromolecule Content

Total Structure Weight: 66.46 kDa
Atom Count: 4,873
Modelled Residue Count: 550
Deposited Residue Count: 570
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Serine/threonine-protein kinase WNK3	A, B	285	Homo sapiens	Mutation(s): 0 Gene Names: WNK3, KIAA1566, PRKWNK3 EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BYP7 (Homo sapiens) Explore Q9BYP7 Go to UniProtKB: Q9BYP7
PHAROS: Q9BYP7 GTEx: ENSG00000196632
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9BYP7
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth B], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
SEP Query on SEP	A, B	L-PEPTIDE LINKING	C₃ H₈ N O₆ P		SER

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.72 Å
R-Value Free: 0.208 (Depositor), 0.210 (DCC)
R-Value Work: 0.173 (Depositor), 0.170 (DCC)
R-Value Observed: 0.175 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.966	α = 90
b = 67.484	β = 94.56
c = 79.895	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2017-06-28

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2017-06-28
Type: Initial release
Version 1.1: 2019-10-16
Changes: Data collection
Version 1.2: 2024-11-20
Changes: Data collection, Database references, Structure summary
