5NKM

SMG8-SMG9 complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.49 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.225
  • R-Value Observed: 0.226

wwPDB Validation   3D Report Full Report


This is version 2.1 of the entry. See complete history


Literature

Structure of a SMG8-SMG9 complex identifies a G-domain heterodimer in the NMD effector proteins.

Li, L.Lingaraju, M.Basquin, C.Basquin, J.Conti, E.

(2017) RNA 23: 1028-1034

  • DOI: https://doi.org/10.1261/rna.061200.117
  • Primary Citation of Related Structures:
    5NKK, 5NKM

  • PubMed Abstract:

    Nonsense-mediated mRNA decay (NMD) is a eukaryotic mRNA degradation pathway involved in surveillance and post-transcriptional regulation, and executed by the concerted action of several trans -acting factors. The SMG1 kinase is an essential NMD factor in metazoans and is associated with two recently identified and yet poorly characterized proteins, SMG8 and SMG9. We determined the 2.5 Å resolution crystal structure of a SMG8-SMG9 core complex from C. elegans We found that SMG8-SMG9 is a G-domain heterodimer with architectural similarities to the dynamin-like family of GTPases such as Atlastin and GBP1. The SMG8-SMG9 heterodimer forms in the absence of nucleotides, with interactions conserved from worms to humans. Nucleotide binding occurs at the G domain of SMG9 but not of SMG8. Fitting the GDP-bound SMG8-SMG9 structure in EM densities of the human SMG1-SMG8-SMG9 complex raises the possibility that the nucleotide site of SMG9 faces SMG1 and could impact the kinase conformation and/or regulation.


  • Organizational Affiliation

    Department of Structural Cell Biology, Max-Planck-Institute of Biochemistry, D-82152 Martinsried, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protein smg-8
A, C
429Caenorhabditis elegansMutation(s): 0
Gene Names: smg-8K04B12.3
UniProt
Find proteins for O62301 (Caenorhabditis elegans)
Explore O62301
Go to UniProtKB:  O62301
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO62301
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Protein smg-9317Caenorhabditis elegansMutation(s): 0
Gene Names: smg-9Y54E2A.2
UniProt
Find proteins for Q9XWJ1 (Caenorhabditis elegans)
Explore Q9XWJ1
Go to UniProtKB:  Q9XWJ1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9XWJ1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Protein smg-9
D, F
305Caenorhabditis elegansMutation(s): 0
Gene Names: smg-9Y54E2A.2
UniProt
Find proteins for Q9XWJ1 (Caenorhabditis elegans)
Explore Q9XWJ1
Go to UniProtKB:  Q9XWJ1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9XWJ1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Protein smg-8419Caenorhabditis elegansMutation(s): 0
Gene Names: smg-8K04B12.3
UniProt
Find proteins for O62301 (Caenorhabditis elegans)
Explore O62301
Go to UniProtKB:  O62301
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO62301
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TRS
Query on TRS

Download Ideal Coordinates CCD File
K [auth C],
U [auth E]
2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
PEG
Query on PEG

Download Ideal Coordinates CCD File
L [auth C],
M [auth C]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
G [auth A]
H [auth A]
I [auth C]
J [auth C]
N [auth D]
G [auth A],
H [auth A],
I [auth C],
J [auth C],
N [auth D],
O [auth D],
P [auth E],
Q [auth E],
R [auth E],
S [auth E],
T [auth E]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, C
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.49 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.225
  • R-Value Observed: 0.226
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 111.085α = 90
b = 111.085β = 90
c = 374.474γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XDSdata scaling
SHELXDphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-04-19
    Type: Initial release
  • Version 1.1: 2017-06-28
    Changes: Database references
  • Version 2.0: 2023-11-15
    Changes: Atomic model, Data collection, Database references, Refinement description
  • Version 2.1: 2024-10-23
    Changes: Structure summary
