5MY2 | pdb_00005my2

KS-MAT DI-DOMAIN OF MOUSE FAS

PDB DOI: https://doi.org/10.2210/pdb5MY2/pdb

Classification: TRANSFERASE
Organism(s): Mus musculus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-01-25 Released: 2018-02-21
Deposition Author(s): Paithankar, K.S., Rittner, A., Vu Huu, K., Grininger, M.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free:
0.251 (Depositor), 0.250 (DCC)
R-Value Work:
0.217 (Depositor), 0.220 (DCC)
R-Value Observed:
0.219 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

KS-MAT DI-DOMAIN OF MOUSE FAS

Paithankar, K.S., Rittner, A., Vu Huu, K., Grininger, M.

To be published.

Macromolecule Content

Total Structure Weight: 369.51 kDa
Atom Count: 25,831
Modelled Residue Count: 3,396
Deposited Residue Count: 3,408
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fatty acid synthase	A, B, C, D	852	Mus musculus	Mutation(s): 0 Gene Names: Fasn EC: 2.3.1.85 (PDB Primary Data), 2.3.1.38 (PDB Primary Data), 2.3.1.39 (PDB Primary Data), 2.3.1.41 (PDB Primary Data), 1.1.1.100 (PDB Primary Data), 4.2.1.59 (PDB Primary Data), 1.3.1.39 (PDB Primary Data), 3.1.2.14 (PDB Primary Data)
UniProt
Find proteins for P19096 (Mus musculus) Explore P19096 Go to UniProtKB: P19096
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P19096
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
COA Query on COA Download Ideal Coordinates CCD File SDF format, chain E [auth D] MOL2 format, chain E [auth D] mmCIF format, chain E [auth D]	E [auth D]	COENZYME A C₂₁ H₃₆ N₇ O₁₆ P₃ S RGJOEKWQDUBAIZ-IBOSZNHHSA-N		Interactions Focus chain E [auth D] Interactions & Density Focus chain E [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free: 0.251 (Depositor), 0.250 (DCC)
R-Value Work: 0.217 (Depositor), 0.220 (DCC)
R-Value Observed: 0.219 (Depositor)

Space Group: C 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 216.565	α = 90
b = 345.81	β = 90
c = 145.229	γ = 90

Software Package:

Software Name	Purpose
Aimless	data scaling
MOLREP	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
MOLREP	phasing
iMOSFLM	data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2018-02-21

Deposition Author(s):

Paithankar, K.S.

Revision History (Full details and data files)

Version 1.0: 2018-02-21
Type: Initial release
Version 1.1: 2024-05-08
Changes: Data collection, Database references, Refinement description
