5MAO | pdb_00005mao

HERA HELICASE RNA BINDING DOMAIN with TNCS in P212121

PDB DOI: https://doi.org/10.2210/pdb5MAO/pdb

Classification: RNA BINDING PROTEIN, HYDROLASE
Organism(s): Thermus thermophilus HB27
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2016-11-03 Released: 2016-12-07
Deposition Author(s): Rudolph, M.G., Klostermeier, D.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.35 Å
R-Value Free:
0.249 (Depositor), 0.252 (DCC)
R-Value Work:
0.238 (Depositor), 0.240 (DCC)
R-Value Observed:
0.238 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5MAO

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of HERA CTD

Rudolph, M.G., Klostermeier, D.

To be published.

Macromolecule Content

Total Structure Weight: 15.3 kDa
Atom Count: 1,194
Modeled Residue Count: 142
Deposited Residue Count: 142
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Heat resistant RNA dependent ATPase	A, B	71	Thermus thermophilus HB27	Mutation(s): 0 Gene Names: TT_C1895
UniProt
Find proteins for Q72GF3 (Thermus thermophilus (strain ATCC BAA-163 / DSM 7039 / HB27)) Explore Q72GF3 Go to UniProtKB: Q72GF3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q72GF3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain C [auth B] MOL2 format, chain C [auth B] mmCIF format, chain C [auth B]	C [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain C [auth B] Interactions & Density Focus chain C [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.35 Å
R-Value Free: 0.249 (Depositor), 0.252 (DCC)
R-Value Work: 0.238 (Depositor), 0.240 (DCC)
R-Value Observed: 0.238 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 38.51	α = 90
b = 48.27	β = 90
c = 64.97	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-12-07

Deposition Author(s):

Klostermeier, D.

Revision History (Full details and data files)

Version 1.0: 2016-12-07
Type: Initial release
Version 1.1: 2024-01-17
Changes: Data collection, Database references, Refinement description
