5KE4 | pdb_00005ke4

Crystal structure of a chimeric acetylcholine binding protein from Aplysia californica (Ac-AChBP) containing loop C from the human alpha 6 nicotinic acetylcholine receptor in complex with 2-((5-(3,7-Diazabicyclo[3.3.1]nonan-3-yl)pyridin-3-yl)oxy)- N,N-dimethylethanamine (BPC)

PDB DOI: https://doi.org/10.2210/pdb5KE4/pdb

Classification: ACETYLCHOLINE-BINDING PROTEIN
Organism(s): Aplysia californica
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2016-06-09 Released: 2016-07-06
Deposition Author(s): Bobango, J., Wu, J., Talley, I.T., Ralston, R., Sankaran, B., Talley, T.T.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.55 Å
R-Value Free:
0.235 (Depositor), 0.237 (DCC)
R-Value Work:
0.187 (Depositor), 0.190 (DCC)
R-Value Observed:
0.189 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5KE4

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of a chimeric acetylcholine binding protein from Aplysia californica (Ac-AChBP) containing loop C from the human alpha 6 nicotinic acetylcholine receptor in complex with 2-((5-(3,7-Diazabicyclo[3.3.1]nonan-3-yl)pyridin-3-yl)oxy)- N,N-dimethylethanamine (BPC)

Bobango, J., Wu, J., Talley, I.T., Ralston, R., Sankaran, B., Talley, T.T.

To be published.

Macromolecule Content

Total Structure Weight: 132.52 kDa
Atom Count: 8,403
Modeled Residue Count: 1,036
Deposited Residue Count: 1,150
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Soluble acetylcholine receptor	A, B, C, D, E	230	Aplysia californica	Mutation(s): 0
UniProt
Find proteins for Q8WSF8 (Aplysia californica) Explore Q8WSF8 Go to UniProtKB: Q8WSF8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8WSF8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
6S7 Query on 6S7 Download:Ideal Coordinates CCD File SDF format, chain I [auth E] SDF format, chain H [auth C] SDF format, chain G [auth B] SDF format, chain F [auth A] MOL2 format, chain I [auth E] MOL2 format, chain H [auth C] MOL2 format, chain G [auth B] MOL2 format, chain F [auth A] mmCIF format, chain I [auth E] mmCIF format, chain H [auth C] mmCIF format, chain G [auth B] mmCIF format, chain F [auth A]	F [auth A], G [auth B], H [auth C], I [auth E]	2-((5-(3,7-Diazabicyclo[3.3.1]nonan-3-yl)pyridin-3-yl)oxy)-N,N-dimethylethanamine C₁₆ H₂₆ N₄ O YXMGPQOPWMCEQM-OKILXGFUSA-N		Interactions Focus chain F [auth A] Focus chain G [auth B] Focus chain H [auth C] Focus chain I [auth E] Interactions & Density Focus chain F [auth A] Focus chain G [auth B] Focus chain H [auth C] Focus chain I [auth E]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.55 Å
R-Value Free: 0.235 (Depositor), 0.237 (DCC)
R-Value Work: 0.187 (Depositor), 0.190 (DCC)
R-Value Observed: 0.189 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 82.999	α = 90
b = 118.782	β = 90
c = 129.178	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-07-06

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2016-07-06
Type: Initial release
Version 1.1: 2024-11-13
Changes: Data collection, Database references, Derived calculations, Structure summary
