5K3N

Crystal structure of Retinoic acid receptor-related orphan receptor (ROR) gamma ligand binding domain complex with ML209

• PDB DOI: https://doi.org/10.2210/pdb5K3N/pdb

• Classification: PROTEIN BINDING
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2016-05-19 Released: 2017-05-31
• Deposition Author(s): Huang, P., Rastinejad, F., Lu, J.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.67 Å
• R-Value Free: 0.285
• R-Value Work: 0.257
• R-Value Observed: 0.258

Literature

Crystal structure of Retinoic acid receptor-related orphan receptor (ROR) gamma ligand binding domain complex with ML209

Huang, P., Rastinejad, F.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 3 assigned by authors and generated by PISA (software)

Biological Assembly 4

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 4 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 116.65 kDa
• Atom Count: 7,604
• Modelled Residue Count: 910
• Deposited Residue Count: 988
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nuclear receptor ROR-gamma	A, B, C, D	247	Homo sapiens	Mutation(s): 0  Gene Names: RORC, NR1F3, RORG, RZRG
UniProt & NIH Common Fund Data Resources
Find proteins for P51449 (Homo sapiens) Explore P51449  Go to UniProtKB:  P51449
PHAROS:  P51449 GTEx:  ENSG00000143365

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
6Q6	E [auth A], F [auth B], G [auth C], H [auth D]	(3S)-3-(2H-1,3-benzodioxol-5-yl)-1-[(3R,5S)-3,5-dimethylpiperidin-1-yl]-3-(2-hydroxy-4,6-dimethoxyphenyl)propan-1-one C25 H31 N O6 YEKVAIMYYCZDLI-FCEWJHQRSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.67 Å
• R-Value Free: 0.285
• R-Value Work: 0.257
• R-Value Observed: 0.258
• Space Group: P 3₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 89.467	α = 90
b = 89.467	β = 90
c = 153.731	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data collection
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2017-05-31
Deposition Author(s): Huang, P., Rastinejad, F., Lu, J.

Revision History

• Version 1.0: 2017-05-31
  Type: Initial release

• Version 1.1: 2024-03-06
  Changes: Data collection, Database references
