5JXD | pdb_00005jxd

Crystal structure of murine Tnfaip8 C165S mutant


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.03 Å
  • R-Value Free:
    0.287 (Depositor), 0.289 (DCC)
  • R-Value Work:
    0.237 (Depositor), 0.246 (DCC)
  • R-Value Observed:
    0.239 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5JXD

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

The Tnfaip8-PE complex is a novel upstream effector in the anti-autophagic action of insulin

Kim, J.S.Park, J.Kim, M.S.Ha, J.Y.Jang, Y.W.Shin, D.H.Son, J.H.

(2017) Sci Rep 7: 6248-6248

  • DOI: https://doi.org/10.1038/s41598-017-06576-3
  • Primary Citation Related Structures:
    5JXD

  • PubMed Abstract:

    Defective hepatic autophagy is observed in obesity and diabetes, whereas autophagy is inhibited by insulin in hepatocytes. Insulin-induced anti-autophagy is mediated by non-canonical Gαi3 signaling via an unknown mechanism. Previously, we identified the anti-autophagic activity of Tnfaip8 via activation of mammalian target of rapamycin (mTOR) in the nervous system. Here, we demonstrate that insulin temporally induces Tnfaip8, which mediates the anti-autophagic action of insulin through formation of a novel ternary complex including Tnfaip8, phosphatidylethanolamine (PE) and Gαi3. Specifically, an X-ray crystallographic study of Tnfaip8 from Mus musculus (mTnfaip8) at 2.03 Å together with LC-MS analyses reveals PE in the hydrophobic cavity. However, an mTnfaip8 mutant lacking PE does not interact with Gαi3, indicating that the PE component is critical for the anti-autophagic action of mTnfaip8 via interaction with Gαi3. Therefore, the mTnfaip8-PE complex may act as an essential upstream effector via ternary complex formation most likely with active Gαi3 during insulin-induced anti-autophagy.


  • Organizational Affiliation
    • College of Pharmacy and Graduate School of Pharmaceutical Sciences, Global Top5 Research Program, Ewha W. University, Seoul, 03760, Republic of Korea.

Macromolecule Content

  • Total Structure Weight: 23.7 kDa
  • Atom Count: 1,589
  • Modeled Residue Count: 186
  • Deposited Residue Count: 198
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Tumor necrosis factor alpha-induced protein 8198Mus musculusMutation(s): 1
UniProt
Find proteins for Q921Z5 (Mus musculus)
Explore Q921Z5
Go to UniProtKB:  Q921Z5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ921Z5
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
6OU

Query on 6OU



Download:Ideal Coordinates CCD File
B [auth A][(2~{R})-1-[2-azanylethoxy(oxidanyl)phosphoryl]oxy-3-hexadecanoyloxy-propan-2-yl] (~{Z})-octadec-9-enoate
C39 H76 N O8 P
FHQVHHIBKUMWTI-OTMQOFQLSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.03 Å
  • R-Value Free:  0.287 (Depositor), 0.289 (DCC)
  • R-Value Work:  0.237 (Depositor), 0.246 (DCC)
  • R-Value Observed: 0.239 (Depositor)
Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.276α = 90
b = 71.57β = 90
c = 90.596γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
DENZOdata reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Education, Science and TechnologyKorea, Republic Of2010K000266

Revision History  (Full details and data files)

  • Version 1.0: 2017-06-28
    Type: Initial release
  • Version 1.1: 2017-11-01
    Changes: Database references
  • Version 1.2: 2023-11-08
    Changes: Data collection, Database references, Refinement description
