5JWK | pdb_00005jwk

Factor Inhibiting HIF D201E in Complex with Fe, and Alpha-Ketoglutarate

• PDB DOI: https://doi.org/10.2210/pdb5JWK/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2016-05-12 Released: 2017-05-17
• Deposition Author(s): Taabazuing, C.Y., Garman, S.C., Knapp, M.J., Eron, S.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.227 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.187 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.190 (Depositor)

Starting Model: experimental

Literature

Factor Inhibiting HIF D201E in Complex with Fe, and Alpha-Ketoglutarate

Hangasky, J.A., Taabazuing, C.Y., Martin, C., Eron, S., Garman, S.C., Knapp, M.J.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 41.12 kDa
• Atom Count: 2,901
• Modeled Residue Count: 341
• Deposited Residue Count: 352
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypoxia-inducible factor 1-alpha inhibitor	A	352	Homo sapiens	Mutation(s): 1  Gene Names: HIF1AN, FIH1 EC: 1.14.11.30 (PDB Primary Data), 1.14.11 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NWT6 (Homo sapiens) Explore Q9NWT6  Go to UniProtKB:  Q9NWT6
PHAROS:  Q9NWT6 GTEx:  ENSG00000166135

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
AKG	B [auth A]	2-OXOGLUTARIC ACID C5 H6 O5 KPGXRSRHYNQIFN-UHFFFAOYSA-N
PEG	C [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
SO4	E [auth A], F [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
FE2	D [auth A]	FE (II) ION Fe CWYNVVGOOAEACU-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.227 (Depositor), 0.230 (DCC)
• R-Value Work:  0.187 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.190 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.131	α = 90
b = 86.131	β = 90
c = 149.213	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data collection
HKL-2000	data scaling
PDB_EXTRACT	data extraction
HKL-2000	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2017-05-17
Deposition Author(s): Taabazuing, C.Y., Garman, S.C., Knapp, M.J., Eron, S.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	T32-GM008515

Revision History

• Version 1.0: 2017-05-17
  Type: Initial release

• Version 2.0: 2017-09-27
  Changes: Author supporting evidence, Polymer sequence
• Version 2.1: 2019-12-25
  Changes: Author supporting evidence
• Version 2.2: 2023-09-27
  Changes: Data collection, Database references, Refinement description
