5JUM | pdb_00005jum

Crystal Structure of Human DNA Polymerase Eta Inserting dCTP Opposite N-(2'-deoxyguanosin-8- yl)-3-aminobenzanthrone (C8-dG-ABA)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:
    0.239 (Depositor), 0.239 (DCC)
  • R-Value Work:
    0.166 (Depositor), 0.169 (DCC)
  • R-Value Observed:
    0.169 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5JUM

Ligand Structure Quality Assessment


This is version 1.5 of the entry. See complete history

Literature

Mechanism of Error-Free Bypass of the Environmental Carcinogen N-(2'-Deoxyguanosin-8-yl)-3-aminobenzanthrone Adduct by Human DNA Polymerase eta.

Patra, A.Politica, D.A.Chatterjee, A.Tokarsky, E.J.Suo, Z.Basu, A.K.Stone, M.P.Egli, M.

(2016) Chembiochem 17: 2033-2037

  • DOI: https://doi.org/10.1002/cbic.201600420
  • Primary Citation Related Structures:
    5JUM

  • PubMed Abstract:

    The environmental pollutant 3-nitrobenzanthrone produces bulky aminobenzanthrone (ABA) DNA adducts with both guanine and adenine nucleobases. A major product occurs at the C8 position of guanine (C8-dG-ABA). These adducts present a strong block to replicative polymerases but, remarkably, can be bypassed in a largely error-free manner by the human Y-family polymerase η (hPol η). Here, we report the crystal structure of a ternary Pol⋅DNA⋅dCTP complex between a C8-dG-ABA-containing template:primer duplex and hPol η. The complex was captured at the insertion stage and provides crucial insight into the mechanism of error-free bypass of this bulky lesion. Specifically, bypass involves accommodation of the ABA moiety inside a hydrophobic cleft to the side of the enzyme active site and formation of an intra-nucleotide hydrogen bond between the phosphate and ABA amino moiety, allowing the adducted guanine to form a standard Watson-Crick pair with the incoming dCTP.


  • Organizational Affiliation
    • Department of Biochemistry, Vanderbilt University, School of Medicine, 868A Robinson Research Building, Nashville, TN, 37232, USA.

Macromolecule Content

  • Total Structure Weight: 55.68 kDa
  • Atom Count: 3,951
  • Modeled Residue Count: 449
  • Deposited Residue Count: 455
  • Unique protein chains: 1
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA polymerase eta435Homo sapiensMutation(s): 0
Gene Names: POLHRAD30RAD30AXPV
EC: 2.7.7.7
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y253 (Homo sapiens)
Explore Q9Y253
Go to UniProtKB:  Q9Y253
PHAROS:  Q9Y253
GTEx:  ENSG00000170734
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Y253
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*C*AP*TP*(4E9)P*AP*TP*GP*AP*CP*GP*CP*T)-3')B [auth T]12synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 3
MoleculeChains LengthOrganismImage
DNA (5'-D(*AP*GP*CP*GP*TP*CP*AP*T)-3')C [auth P]8synthetic construct
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:  0.239 (Depositor), 0.239 (DCC)
  • R-Value Work:  0.166 (Depositor), 0.169 (DCC)
  • R-Value Observed: 0.169 (Depositor)
Space Group: P 61
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.117α = 90
b = 99.117β = 90
c = 81.69γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesCA160032
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesCA55678
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesES05509
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesES009127
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesES021762
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesCA68485

Revision History  (Full details and data files)

  • Version 1.0: 2016-09-07
    Type: Initial release
  • Version 1.1: 2017-09-20
    Changes: Author supporting evidence, Derived calculations
  • Version 1.2: 2018-04-18
    Changes: Data collection, Database references
  • Version 1.3: 2019-01-16
    Changes: Data collection, Source and taxonomy
  • Version 1.4: 2022-03-23
    Changes: Author supporting evidence, Database references, Derived calculations
  • Version 1.5: 2023-09-27
    Changes: Data collection, Refinement description
