5JTH | pdb_00005jth

Crystal structure of E67A calmodulin - CaM:RM20 analog complex

• PDB DOI: https://doi.org/10.2210/pdb5JTH/pdb

• Classification: TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2016-05-09 Released: 2017-07-19
• Deposition Author(s): Grum-Tokars, V.L., Minasov, G., Anderson, W.F., Watterson, D.M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.84 Å
• R-Value Free:
  0.196 (Depositor), 0.203 (DCC)
• R-Value Work:
  0.157 (Depositor), 0.169 (DCC)
• R-Value Observed:
  0.159 (Depositor)

Literature

Crystal structure of E67A calmodulin - CaM:RM20 analog complex

Grum-Tokars, V.L., Minasov, G., Anderson, W.F., Watterson, D.M.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 19.3 kDa
• Atom Count: 1,560
• Modeled Residue Count: 168
• Deposited Residue Count: 171
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Calmodulin	A	149	Homo sapiens	Mutation(s): 1  Gene Names:  CALM1, CALM, CAM, CAM1, CALM2, CAM2, CAMB, CALM3, CALML2, CAM3, CAMC, CAMIII
UniProt & NIH Common Fund Data Resources
Find proteins for P0DP23 (Homo sapiens) Explore P0DP23  Go to UniProtKB:  P0DP23
PHAROS:  P0DP23 GTEx:  ENSG00000198668

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Myosin light chain kinase, smooth muscle	B	22	Homo sapiens	Mutation(s): 2  EC: 2.7.11.18
UniProt & NIH Common Fund Data Resources
Find proteins for Q15746 (Homo sapiens) Explore Q15746  Go to UniProtKB:  Q15746
PHAROS:  Q15746 GTEx:  ENSG00000065534

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CA	C [auth A], D [auth A], E [auth A], F [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.84 Å
• R-Value Free:  0.196 (Depositor), 0.203 (DCC)
• R-Value Work:  0.157 (Depositor), 0.169 (DCC)
• R-Value Observed: 0.159 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 29.094	α = 90
b = 57.053	β = 97.18
c = 44.871	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2017-07-19
Deposition Author(s): Grum-Tokars, V.L., Minasov, G., Anderson, W.F., Watterson, D.M.

Revision History

• Version 1.0: 2017-07-19
  Type: Initial release

• Version 1.1: 2024-03-06
  Changes: Data collection, Database references, Derived calculations, Structure summary
• Version 1.2: 2024-10-09
  Changes: Structure summary
