5JQJ

Directed evolutionary changes in MBL super family - NDM-1 Round 10 crystal-1

• PDB DOI: https://doi.org/10.2210/pdb5JQJ/pdb

• Classification: HYDROLASE
• Organism(s): Klebsiella pneumoniae
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2016-05-05 Released: 2017-05-10
• Deposition Author(s): Hong, N.-S., Jackson, C.J., Carr, P.D.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.67 Å
• R-Value Free: 0.187
• R-Value Work: 0.144
• R-Value Observed: 0.147

Starting Model: experimental

Literature

Enzyme evolvability is contingent on the initial sequence background

Baier, F., Hong, N.-S., Yang, G., Carr, P.D., Jackson, C., Tokuriki, N.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 26.56 kDa
• Atom Count: 2,052
• Modelled Residue Count: 228
• Deposited Residue Count: 245
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Metallo-beta-lactamase type 2	A	245	Klebsiella pneumoniae	Mutation(s): 13  Gene Names: blaNDM-1 EC: 3.5.2.6
UniProt
Find proteins for C7C422 (Klebsiella pneumoniae) Explore C7C422  Go to UniProtKB:  C7C422

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MES	D [auth A], E [auth A]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C6 H13 N O4 S SXGZJKUKBWWHRA-UHFFFAOYSA-N
ZN	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG	F [auth A], G [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.67 Å
• R-Value Free: 0.187
• R-Value Work: 0.144
• R-Value Observed: 0.147
• Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 37.795	α = 90
b = 137.724	β = 90
c = 77.455	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2017-05-10
Deposition Author(s): Hong, N.-S., Jackson, C.J., Carr, P.D.

Revision History

• Version 1.0: 2017-05-10
  Type: Initial release

• Version 1.1: 2017-09-27
  Changes: Author supporting evidence
• Version 1.2: 2023-09-27
  Changes: Data collection, Database references, Derived calculations, Refinement description
