5JEA

Structure of a cytoplasmic 11-subunit RNA exosome complex including Ski7, bound to RNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.215
  • R-Value Observed: 0.217

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure of a Cytoplasmic 11-Subunit RNA Exosome Complex.

Kowalinski, E.Kogel, A.Ebert, J.Reichelt, P.Stegmann, E.Habermann, B.Conti, E.

(2016) Mol Cell 63: 125-134

  • DOI: https://doi.org/10.1016/j.molcel.2016.05.028
  • Primary Citation of Related Structures:
    5JEA

  • PubMed Abstract:

    The RNA exosome complex associates with nuclear and cytoplasmic cofactors to mediate the decay, surveillance, or processing of a wide variety of transcripts. In the cytoplasm, the conserved core of the exosome (Exo10) functions together with the conserved Ski complex. The interaction of S. cerevisiae Exo10 and Ski is not direct but requires a bridging cofactor, Ski7. Here, we report the 2.65 Å resolution structure of S. cerevisiae Exo10 bound to the interacting domain of Ski7. Extensive hydrophobic interactions rationalize the high affinity and stability of this complex, pointing to Ski7 as a constitutive component of the cytosolic exosome. Despite the absence of sequence homology, cytoplasmic Ski7 and nuclear Rrp6 bind Exo10 using similar surfaces and recognition motifs. Knowledge of the interacting residues in the yeast complexes allowed us to identify a splice variant of human HBS1-Like as a Ski7-like exosome-binding protein, revealing the evolutionary conservation of this cytoplasmic cofactor.


  • Organizational Affiliation

    Department of Structural Cell Biology, Max Planck Institute of Biochemistry, Am Klopferspitz 18, 82152 Martinsried, Germany.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component RRP45305Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRP45YDR280WD9954.1
UniProt
Find proteins for Q05636 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q05636
Go to UniProtKB:  Q05636
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ05636
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component SKI6249Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: SKI6ECM20RRP41YGR195WG7587
UniProt
Find proteins for P46948 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P46948
Go to UniProtKB:  P46948
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP46948
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component RRP43394Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRP43YCR035CYCR35CYCR522
UniProt
Find proteins for P25359 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P25359
Go to UniProtKB:  P25359
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25359
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component RRP46226Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRP46YGR095C
UniProt
Find proteins for P53256 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P53256
Go to UniProtKB:  P53256
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53256
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component RRP42268Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRP42YDL111C
UniProt
Find proteins for Q12277 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12277
Go to UniProtKB:  Q12277
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12277
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component MTR3250Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: MTR3YGR158CG6676
UniProt
Find proteins for P48240 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P48240
Go to UniProtKB:  P48240
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP48240
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component RRP40244Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRP40YOL142W
UniProt
Find proteins for Q08285 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q08285
Go to UniProtKB:  Q08285
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08285
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component RRP4316Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRP4YHR069C
UniProt
Find proteins for P38792 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38792
Go to UniProtKB:  P38792
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38792
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex component CSL4295Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: CSL4SKI4YNL232WN1154
UniProt
Find proteins for P53859 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P53859
Go to UniProtKB:  P53859
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53859
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Exosome complex exonuclease DIS31,005Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: DIS3RRP44YOL021CO2197
EC: 3.1.13 (PDB Primary Data), 3.1.26 (PDB Primary Data)
UniProt
Find proteins for Q08162 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q08162
Go to UniProtKB:  Q08162
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08162
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Superkiller protein 7,Endolysin279Saccharomyces cerevisiae S288CTequatrovirus T4
This entity is chimeric
Mutation(s): 0
Gene Names: SKI7YOR076CYOR29-27
EC: 3.2.1.17
UniProt
Find proteins for Q08491 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q08491
Go to UniProtKB:  Q08491
Find proteins for P00720 (Enterobacteria phage T4)
Explore P00720
Go to UniProtKB:  P00720
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP00720Q08491
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains LengthOrganismImage
RNA (29-MER)L [auth R]46synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MPD
Query on MPD

Download Ideal Coordinates CCD File
M [auth A]
N [auth A]
Q [auth C]
R [auth D]
T [auth G]
M [auth A],
N [auth A],
Q [auth C],
R [auth D],
T [auth G],
U [auth G],
V [auth J]
(4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
W [auth J]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
NA
Query on NA

Download Ideal Coordinates CCD File
O [auth B],
P [auth B],
S [auth F],
X [auth J]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.215
  • R-Value Observed: 0.217
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 106.08α = 90
b = 182.53β = 90
c = 250.55γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Research CouncilGermany294371
German Research FoundationGermanySFB646
German Research FoundationGermanySFB1035
German Research FoundationGermanyGRK1721
German Research FoundationGermanyFOR1680
German Research FoundationGermanyCIPSM

Revision History  (Full details and data files)

  • Version 1.0: 2016-07-13
    Type: Initial release
  • Version 1.1: 2016-08-24
    Changes: Atomic model, Database references
  • Version 1.2: 2024-01-10
    Changes: Author supporting evidence, Data collection, Database references, Derived calculations, Refinement description
