5HWH | pdb_00005hwh

Structure of a cysteine hydrolase with a positive substrate

PDB DOI: https://doi.org/10.2210/pdb5HWH/pdb

Classification: HYDROLASE
Organism(s): Microbacterium hydrocarbonoxydans
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2016-01-29 Released: 2017-02-01
Deposition Author(s): Feng, Y., Gao, S.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.79 Å
R-Value Free:
0.220 (Depositor), 0.206 (DCC)
R-Value Work:
0.184 (Depositor), 0.173 (DCC)
R-Value Observed:
0.186 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5HWH

This is version 1.2 of the entry. See complete history.

Literature

Structure of a cysteine hydrolase

Gao, S., Feng, Y.

To be published.

Macromolecule Content

Total Structure Weight: 20.53 kDa
Atom Count: 1,583
Modeled Residue Count: 175
Deposited Residue Count: 187
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isochorismatase	A	187	Microbacterium hydrocarbonoxydans	Mutation(s): 1
UniProt
Find proteins for A0A0K0XHU0 (Microbacterium hydrocarbonoxydans) Explore A0A0K0XHU0 Go to UniProtKB: A0A0K0XHU0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0K0XHU0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
66Z Query on 66Z Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(1~{S},4~{R})-3-azabicyclo[2.2.1]hept-5-en-2-one C₆ H₇ N O DDUFYKNOXPZZIW-UHNVWZDZSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.79 Å
R-Value Free: 0.220 (Depositor), 0.206 (DCC)
R-Value Work: 0.184 (Depositor), 0.173 (DCC)
R-Value Observed: 0.186 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.427	α = 90
b = 69.427	β = 90
c = 87.159	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
SCALEPACK	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-02-01

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2017-02-01
Type: Initial release
Version 1.1: 2019-02-20
Changes: Data collection, Source and taxonomy
Version 1.2: 2024-03-20
Changes: Data collection, Database references
