5FYF | pdb_00005fyf

Structure of CYP153A from Marinobacter aquaeolei

PDB DOI: https://doi.org/10.2210/pdb5FYF/pdb

Classification: OXIDOREDUCTASE
Organism(s): Marinobacter nauticus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2016-03-07 Released: 2017-01-18
Deposition Author(s): Danesh Azari, H.R., Spandolf, C., Hoffman, S.M., Weissenborn, M., Hauer, B., Grogan, G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.04 Å
R-Value Free:
0.237 (Depositor), 0.272 (DCC)
R-Value Work:
0.198 (Depositor), 0.261 (DCC)
R-Value Observed:
0.200 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Structure-Guided Redesign of CYP153AM.aqfor the Improved Terminal Hydroxylation of Fatty Acids

Hoffman, S.M., Danesh Azari, H.-R., Spandolf, C., Weissenborn, M., Grogan, G., Hauer, B.

(2016) ChemCatChem

DOI: https://doi.org/10.1002/cctc.201600680

Macromolecule Content

Total Structure Weight: 109.46 kDa
Atom Count: 6,869
Modeled Residue Count: 831
Deposited Residue Count: 940
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CYTOCHROME P450	A, B	470	Marinobacter nauticus	Mutation(s): 0
UniProt
Find proteins for A1TY82 (Marinobacter nauticus (strain ATCC 700491 / DSM 11845 / VT8)) Explore A1TY82 Go to UniProtKB: A1TY82
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A1TY82
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HEM Query on HEM Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain F [auth B] MOL2 format, chain C [auth A] MOL2 format, chain F [auth B] mmCIF format, chain C [auth A] mmCIF format, chain F [auth B]	C [auth A], F [auth B]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain C [auth A] Focus chain F [auth B] Interactions & Density Focus chain C [auth A] Focus chain F [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain G [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain G [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain G [auth B]	D [auth A], E [auth A], G [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain G [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain G [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.04 Å
R-Value Free: 0.237 (Depositor), 0.272 (DCC)
R-Value Work: 0.198 (Depositor), 0.261 (DCC)
R-Value Observed: 0.200 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.59	α = 90
b = 71.11	β = 90
c = 215.18	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
SCALA	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-01-18

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2017-01-18
Type: Initial release
Version 1.1: 2024-01-10
Changes: Data collection, Database references, Derived calculations, Other, Refinement description
