5F5X | pdb_00005f5x

Crystal structure of S116A Ba3275 with AMP bound

PDB DOI: https://doi.org/10.2210/pdb5F5X/pdb

Classification: HYDROLASE
Organism(s): Bacillus cereus ATCC 10987
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): Yes

Deposited: 2015-12-04 Released: 2015-12-30
Deposition Author(s): Nocek, B., Severinov, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.01 Å
R-Value Free:
0.247 (Depositor), 0.251 (DCC)
R-Value Work:
0.213 (Depositor), 0.219 (DCC)
R-Value Observed:
0.215 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5F5X

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of Ba3275-AMP complex from Bacillus cereus ATCC 10987

Nocek, B., Severinov, K., Anderson, W.F., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 80.81 kDa
Atom Count: 5,854
Modeled Residue Count: 688
Deposited Residue Count: 692
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MccC family protein Ba3275	A, B	346	Bacillus cereus ATCC 10987	Mutation(s): 2 Gene Names: BCE_3281
UniProt
Find proteins for Q734X3 (Bacillus cereus (strain ATCC 10987 / NRS 248)) Explore Q734X3 Go to UniProtKB: Q734X3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q734X3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
AMP Query on AMP Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B]	C [auth A], D [auth B]	ADENOSINE MONOPHOSPHATE C₁₀ H₁₄ N₅ O₇ P UDMBCSSLTHHNCD-KQYNXXCUSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.01 Å
R-Value Free: 0.247 (Depositor), 0.251 (DCC)
R-Value Work: 0.213 (Depositor), 0.219 (DCC)
R-Value Observed: 0.215 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.116	α = 90
b = 117.728	β = 95.27
c = 54.852	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-12-30

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2015-12-30
Type: Initial release
Version 1.1: 2016-01-20
Changes: Structure summary
Version 1.2: 2017-02-08
Changes: Structure summary
Version 1.3: 2024-10-30
Changes: Data collection, Database references, Structure summary
