5F5N | pdb_00005f5n

The structure of monooxygenase KstA11 in complex with NAD and its substrate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free:
    0.166 (Depositor), 0.168 (DCC)
  • R-Value Work:
    0.143 (Depositor), 0.148 (DCC)
  • R-Value Observed:
    0.145 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5F5N

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Hydroxyl regioisomerization of anthracycline catalyzed by a four-enzyme cascade

Zhang, Z.Gong, Y.-K.Zhou, Q.Hu, Y.Ma, H.-M.Chen, Y.-S.Igarashi, Y.Pan, L.Tang, G.-L.

(2017) Proc Natl Acad Sci U S A 114: 1554-1559

  • DOI: https://doi.org/10.1073/pnas.1610097114
  • Primary Citation Related Structures:
    5F5L, 5F5N

  • PubMed Abstract:

    Ranking among the most effective anticancer drugs, anthracyclines represent an important family of aromatic polyketides generated by type II polyketide synthases (PKSs). After formation of polyketide cores, the post-PKS tailoring modifications endow the scaffold with various structural diversities and biological activities. Here we demonstrate an unprecedented four-enzyme-participated hydroxyl regioisomerization process involved in the biosynthesis of kosinostatin. First, KstA15 and KstA16 function together to catalyze a cryptic hydroxylation of the 4-hydroxyl-anthraquinone core, yielding a 1,4-dihydroxyl product, which undergoes a chemically challenging asymmetric reduction-dearomatization subsequently acted by KstA11; then, KstA10 catalyzes a region-specific reduction concomitant with dehydration to afford the 1-hydroxyl anthraquinone. Remarkably, the shunt product identifications of both hydroxylation and reduction-dehydration reactions, the crystal structure of KstA11 with bound substrate and cofactor, and isotope incorporation experiments reveal mechanistic insights into the redox dearomatization and rearomatization steps. These findings provide a distinguished tailoring paradigm for type II PKS engineering.


  • Organizational Affiliation
    • State Key Laboratory of Bio-organic and Natural Products Chemistry, Shanghai Institute of Organic Chemistry, Chinese Academy of Sciences, Shanghai 200032, China.

Macromolecule Content

  • Total Structure Weight: 64.98 kDa
  • Atom Count: 5,747
  • Modeled Residue Count: 578
  • Deposited Residue Count: 578
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Monooxygenase
A, B
289Micromonospora okiiMutation(s): 0
UniProt
Find proteins for A0A023GUL3 (Micromonospora okii)
Explore A0A023GUL3
Go to UniProtKB:  A0A023GUL3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A023GUL3
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAD

Query on NAD



Download:Ideal Coordinates CCD File
C [auth A],
J [auth B]
NICOTINAMIDE-ADENINE-DINUCLEOTIDE
C21 H27 N7 O14 P2
BAWFJGJZGIEFAR-NNYOXOHSSA-N
5VD

Query on 5VD



Download:Ideal Coordinates CCD File
D [auth A],
K [auth B]
methyl (1~{R},2~{R},4~{S})-2-methyl-2,4,5,7,10-pentakis(oxidanyl)-6,11-bis(oxidanylidene)-3,4-dihydro-1~{H}-tetracene-1-carboxylate
C21 H18 O9
ZBSRQGXAWDQXFX-SBOBAANCSA-N
EPE

Query on EPE



Download:Ideal Coordinates CCD File
Q [auth B],
R [auth B]
4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID
C8 H18 N2 O4 S
JKMHFZQWWAIEOD-UHFFFAOYSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
E [auth A]
F [auth A]
G [auth A]
H [auth A]
I [auth A]
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
L [auth B],
M [auth B],
N [auth B],
O [auth B],
P [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
S [auth B]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free:  0.166 (Depositor), 0.168 (DCC)
  • R-Value Work:  0.143 (Depositor), 0.148 (DCC)
  • R-Value Observed: 0.145 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.476α = 90
b = 66.025β = 90
c = 176.319γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data processing
Cootmodel building
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Basic Research Program of ChinaChina2013CB836900
a Shanghai Rising Star Scholar awardChina13QA1404300

Revision History  (Full details and data files)

  • Version 1.0: 2016-12-21
    Type: Initial release
  • Version 1.1: 2017-02-08
    Changes: Database references
  • Version 1.2: 2017-03-01
    Changes: Database references
  • Version 1.3: 2023-11-08
    Changes: Data collection, Database references, Refinement description
