5CY1 | pdb_00005cy1

Tn3 resolvase - site III complex crystal form I

PDB DOI: https://doi.org/10.2210/pdb5CY1/pdb
NAKB: 5CY1

Classification: HYDROLASE, LIGASE/DNA
Organism(s): Escherichia coli
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2015-07-30 Released: 2017-01-11
Deposition Author(s): Montano, S.P., Rice, P.A.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.40 Å
R-Value Free:
0.292 (Depositor), 0.317 (DCC)
R-Value Work:
0.248 (Depositor), 0.255 (DCC)
R-Value Observed:
0.251 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5CY1

This is version 1.3 of the entry. See complete history.

Literature

Tn3 resolvase - accessory site complexes: DNA geometry dictates complex geometry

Montano, S.P., Rice, P.A.

To be published.

Macromolecule Content

Total Structure Weight: 61.55 kDa
Atom Count: 4,072
Modeled Residue Count: 423
Deposited Residue Count: 444
Unique protein chains: 1
Unique nucleic acid chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transposon Tn3 resolvase	A, B	192	Escherichia coli	Mutation(s): 0 Gene Names: tnpR
UniProt
Find proteins for P0ADI2 (Escherichia coli) Explore P0ADI2 Go to UniProtKB: P0ADI2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0ADI2
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff)

Molecule	Chains	Length	Organism	Image
Entity ID: 2
DNA (30-MER)	C	30	N/A
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff)

Molecule	Chains	Length	Organism	Image
Entity ID: 3
DNA (30-MER)	D	30	N/A
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.40 Å
R-Value Free: 0.292 (Depositor), 0.317 (DCC)
R-Value Work: 0.248 (Depositor), 0.255 (DCC)
R-Value Observed: 0.251 (Depositor)

Diffraction Data:

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 77.313	α = 90
b = 77.313	β = 90
c = 272.277	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
SHELXDE	phasing
SOLVE	phasing
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2017-01-11

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R01GM086826

Revision History (Full details and data files)

Version 1.0: 2017-01-11
Type: Initial release
Version 1.1: 2017-09-20
Changes: Author supporting evidence
Version 1.2: 2019-12-25
Changes: Author supporting evidence
Version 1.3: 2024-03-06
Changes: Data collection, Database references
