5CM8 | pdb_00005cm8

Structural Basis for the Selectivity of Guanine Nucleotide Exchange Factors for the small G-protein Ral


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:
    0.322 (Depositor), 0.317 (DCC)
  • R-Value Work:
    0.259 (Depositor), 0.254 (DCC)
  • R-Value Observed:
    0.262 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5CM8

This is version 1.2 of the entry. See complete history

Literature

The structure of the Guanine Nucleotide Exchange Factor Rlf in complex with the small G-protein Ral identifies conformational intermediates of the exchange reaction and the basis for the selectivity.

Popovic, M.Schouten, A.Rensen-de Leeuw, M.Rehmann, H.

(2016) J Struct Biol 193: 106-114

  • DOI: https://doi.org/10.1016/j.jsb.2015.12.006
  • Primary Citation Related Structures:
    5CM8, 5CM9

  • PubMed Abstract:

    CDC25 homology domain (CDC25-HD) containing Guanine Nucleotide Exchange Factors (GEFs) initiate signalling by small G-proteins of the Ras-family. Each GEF acts on a small subset of the G-proteins only, thus providing signalling selectivity. Rlf is a GEF with selectivity for the G-proteins RalA and RalB. Here the crystal structure of Rlf in complex with Ral is determined. The Rlf·Ral complex crystallised into two different crystal forms, which represent different steps of the exchange reaction. Thereby general insight in the CDC25-HD catalysed nucleotide exchange is obtained. In addition, the basis for the selectivity of the interaction is investigated. The exchange activity is monitored by the use of recombinant proteins. Selectivity determinants in the binding interface are identified and confirmed by a mutational study.


  • Organizational Affiliation
    • Department of Molecular Cancer Research, Centre of Biomedical Genetics and Cancer Genomics Centre, University Medical Center Utrecht, Utrecht, The Netherlands.

Macromolecule Content

  • Total Structure Weight: 75.23 kDa
  • Atom Count: 4,634
  • Modeled Residue Count: 588
  • Deposited Residue Count: 676
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ral guanine nucleotide dissociation stimulator-like 2473Mus musculusMutation(s): 0
Gene Names: Rgl2Rab2lRlf
UniProt
Find proteins for Q61193 (Mus musculus)
Explore Q61193
Go to UniProtKB:  Q61193
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ61193
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Ras-related protein Ral-a203Drosophila melanogasterMutation(s): 0
Gene Names: RalaCG2849
EC: 3.6.5.2
UniProt
Find proteins for P48555 (Drosophila melanogaster)
Explore P48555
Go to UniProtKB:  P48555
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP48555
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:  0.322 (Depositor), 0.317 (DCC)
  • R-Value Work:  0.259 (Depositor), 0.254 (DCC)
  • R-Value Observed: 0.262 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 111.11α = 90
b = 98.49β = 91.61
c = 71.32γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XSCALEdata scaling
XDSdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-01-13
    Type: Initial release
  • Version 1.1: 2016-02-03
    Changes: Database references
  • Version 1.2: 2024-01-10
    Changes: Data collection, Database references, Refinement description
