5BZX

Crystal structure of human phosphatase PTEN treated with a bisperoxovanadium complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.204
  • R-Value Work: 0.175
  • R-Value Observed: 0.177

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 2.1 of the entry. See complete history


Literature

Redox Modulation of PTEN Phosphatase Activity by Hydrogen Peroxide and Bisperoxidovanadium Complexes.

Lee, C.U.Hahne, G.Hanske, J.Bange, T.Bier, D.Rademacher, C.Hennig, S.Grossmann, T.N.

(2015) Angew Chem Int Ed Engl 54: 13796-13800

  • DOI: https://doi.org/10.1002/anie.201506338
  • Primary Citation of Related Structures:
    5BUG, 5BZX, 5BZZ

  • PubMed Abstract:

    PTEN is a dual-specificity protein tyrosine phosphatase. As one of the central tumor suppressors, a thorough regulation of its activity is essential for proper cellular homeostasis. The precise implications of PTEN inhibition by reactive oxygen species (e.g. H2 O2 ) and the subsequent structural consequences remain elusive. To study the effects of PTEN inhibition, bisperoxidovanadium (bpV) complexes serve as important tools with the potential for the treatment of nerve injury or cardiac ischemia. However, their mode of action is unknown, hampering further optimization and preventing therapeutic applications. Based on protein crystallography, mass spectrometry, and NMR spectroscopy, we elucidate the molecular basis of PTEN inhibition by H2O2 and bpV complexes. We show that both molecules inhibit PTEN via oxidative mechanisms resulting in the formation of the same intramolecular disulfide, therefore enabling the reactivation of PTEN under reductive conditions.


  • Organizational Affiliation

    Chemical Genomics Centre of the Max Planck Society, Otto-Hahn-Strasse 15, 44227 Dortmund (Germany).


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Phosphatidylinositol 3,4,5-trisphosphate 3-phosphatase and dual-specificity protein phosphatase PTEN
A, B, C, D
314Homo sapiensMutation(s): 0
Gene Names: PTENMMAC1TEP1
EC: 3.1.3.16 (PDB Primary Data), 3.1.3.48 (PDB Primary Data), 3.1.3.67 (PDB Primary Data), 3.1.3 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P60484 (Homo sapiens)
Explore P60484
Go to UniProtKB:  P60484
PHAROS:  P60484
GTEx:  ENSG00000171862
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60484
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.204
  • R-Value Work: 0.175
  • R-Value Observed: 0.177
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 207.06α = 90
b = 206.9β = 90
c = 87.67γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XSCALEdata scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research FoundationGermanyGR3592/2-1

Revision History  (Full details and data files)

  • Version 1.0: 2015-10-07
    Type: Initial release
  • Version 1.1: 2015-11-11
    Changes: Database references
  • Version 2.0: 2024-01-10
    Changes: Atomic model, Author supporting evidence, Data collection, Database references, Refinement description
  • Version 2.1: 2024-11-20
    Changes: Structure summary
