Structure of the yeast F1FO ATPase C10 ring with 21-hydroxy-oligomycin
Mueller, D.M.To be published.
Experimental Data Snapshot
Starting Model: experimental
View more details
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
ATP synthase subunit 9, mitochondrial | 76 | Saccharomyces cerevisiae | Mutation(s): 0  EC: 3.6 Membrane Entity: Yes  | ![]() | |
UniProt | |||||
Find proteins for P61829 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore P61829  Go to UniProtKB:  P61829 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | P61829 | ||||
Sequence AnnotationsExpand | |||||
|
Ligands 1 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
E21 Query on E21 | K [auth B] L [auth B] M [auth E] N [auth K] O [auth L] | 21-hydroxy-oligomycin C45 H74 O12 SCVGLVGTMYJVOI-AAYFJTACSA-N |
Modified Residues 1 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Type | Formula | 2D Diagram | Parent |
FME Query on FME | A B C D E A, B, C, D, E, F [auth K], G [auth L], H [auth M], I [auth N], J [auth O] | L-PEPTIDE LINKING | C6 H11 N O3 S | MET |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 75.975 | α = 90 |
b = 75.975 | β = 90 |
c = 489.218 | γ = 90 |
Software Name | Purpose |
---|---|
REFMAC | refinement |
HKL-2000 | data reduction |
HKL-2000 | data scaling |
REFMAC | phasing |
