5AHA

Disubstituted bis-THF moieties as new P2 ligands in non-peptidal HIV- 1 Protease Inhibitors (II)

• PDB DOI: https://doi.org/10.2210/pdb5AHA/pdb

• Classification: HYDROLASE
• Organism(s): Human immunodeficiency virus type 1 (Z2/CDC-Z34 ISOLATE)
• Expression System: Escherichia coli BL21
• Mutation(s): Yes


• Deposited: 2015-02-05 Released: 2015-05-06
• Deposition Author(s): Hohlfeld, K., Wegner, J.K., Kesteleyn, B., Linclau, B., Unge, J.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.35 Å
• R-Value Free: 0.225
• R-Value Work: 0.209
• R-Value Observed: 0.210

Starting Model: other

Literature

Disubstituted Bis-Thf Moieties as New P2 Ligands in Non-Peptidal HIV-1 Protease Inhibitors (II).

Hohlfeld, K., Wegner, J., Kesteleyn, B., Linclau, B., Unge, J.

(2015) J Med Chem 58: 4029

• PubMed: 25897791
• DOI: https://doi.org/10.1021/acs.jmedchem.5b00358
• Primary Citation of Related Structures:
  5AGZ, 5AH6, 5AH7, 5AH8, 5AH9, 5AHA, 5AHB, 5AHC


• PubMed Abstract:


  A series of darunavir analogues featuring a substituted bis-THF ring as P2 ligand have been synthesized and evaluated. Very high affinity protease inhibitors (PIs) with an interesting activity on wild-type HIV and a panel of multi-PI resistant HIV-1 mutants containing clinically observed, primary mutations were identified using a cell-based assay. Crystal structure analysis was conducted on a number of PI analogues in complex with HIV-1 protease.

---

Organizational Affiliation:

†University of Southampton, School of Chemistry, Highfield, Southampton SO17 1BJ, United Kingdom.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 22.33 kDa
• Atom Count: 1,892
• Modelled Residue Count: 198
• Deposited Residue Count: 198
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PROTEASE	A, B	99	Human immunodeficiency virus type 1 (Z2/CDC-Z34 ISOLATE)	Mutation(s): 3  EC: 3.4.23.16
UniProt
Find proteins for P03366 (Human immunodeficiency virus type 1 group M subtype B (isolate BH10)) Explore P03366  Go to UniProtKB:  P03366

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZLP	D [auth A]	(3R,3aS,4R,6aR)-4-(2-methoxyethoxy)hexahydrofuro[2,3-b]furan-3-yl {(2S,3R)-3-hydroxy-4-[{[(2Z)-2-(methylimino)-2,3-dihydro-1,3-benzoxazol-6-yl]sulfonyl}(2-methylpropyl)amino]-1-phenylbutan-2-yl}carbamate C32 H44 N4 O10 S RAYAFQVLXHNDSC-CFUDKJTHSA-N
CL	C [auth A], E [auth B], F [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.35 Å
• R-Value Free: 0.225
• R-Value Work: 0.209
• R-Value Observed: 0.210
• Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.376	α = 90
b = 85.958	β = 90
c = 46.436	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
iMOSFLM	data reduction
SCALA	data scaling
REFMAC	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2015-05-06
Deposition Author(s): Hohlfeld, K., Wegner, J.K., Kesteleyn, B., Linclau, B., Unge, J.

Revision History

• Version 1.0: 2015-05-06
  Type: Initial release

• Version 1.1: 2015-05-27
  Changes: Database references
• Version 1.2: 2018-01-17
  Changes: Data collection
• Version 1.3: 2024-05-01
  Changes: Data collection, Database references, Derived calculations, Other, Refinement description
