5AFA | pdb_00005afa

Crystal structure of Laccase from Thermus thermophilus HB27 complexed with Ag, crystal of the holoenzyme soaked for 30 m in 5 mM AgNO3 at 278 K.

PDB DOI: https://doi.org/10.2210/pdb5AFA/pdb

Classification: OXIDOREDUCTASE
Organism(s): Thermus thermophilus HB27
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2015-01-19 Released: 2016-02-17
Deposition Author(s): Jimenez-Arroyo, N., Rudino-Pinera, E.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.19 Å
R-Value Free:
0.194 (Depositor), 0.194 (DCC)
R-Value Work:
0.146 (Depositor), 0.147 (DCC)
R-Value Observed:
0.148 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Structural Function of the Methionine-Rich Beta-Hairpin in the Laccase for T. Thermophilus.

Jimenez-Arroyo, N., Cardona-Felix, C.S., Rojas-Trejo, S.P., Rudino-Pinera, E.

To be published.

Macromolecule Content

Total Structure Weight: 51.04 kDa
Atom Count: 4,192
Modeled Residue Count: 439
Deposited Residue Count: 439
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
LACCASE	A	439	Thermus thermophilus HB27	Mutation(s): 0 EC: 1.10.3.2
UniProt
Find proteins for Q72HW2 (Thermus thermophilus (strain ATCC BAA-163 / DSM 7039 / HB27)) Explore Q72HW2 Go to UniProtKB: Q72HW2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q72HW2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MPD Query on MPD Download:Ideal Coordinates CCD File SDF format, chain N [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain B [auth A] MOL2 format, chain N [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain B [auth A] mmCIF format, chain N [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain B [auth A]	B [auth A] I [auth A] J [auth A] K [auth A] L [auth A] B [auth A], I [auth A], J [auth A], K [auth A], L [auth A], N [auth A]	(4S)-2-METHYL-2,4-PENTANEDIOL C₆ H₁₄ O₂ SVTBMSDMJJWYQN-YFKPBYRVSA-N		Interactions Focus chain B [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain N [auth A] Interactions & Density Focus chain B [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain N [auth A]
MRD Query on MRD Download:Ideal Coordinates CCD File SDF format, chain O [auth A] SDF format, chain M [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain O [auth A] MOL2 format, chain M [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain O [auth A] mmCIF format, chain M [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], M [auth A], O [auth A]	(4R)-2-METHYLPENTANE-2,4-DIOL C₆ H₁₄ O₂ SVTBMSDMJJWYQN-RXMQYKEDSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain M [auth A] Focus chain O [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain M [auth A] Focus chain O [auth A]
AG Query on AG Download:Ideal Coordinates CCD File SDF format, chain R [auth A] SDF format, chain Q [auth A] SDF format, chain P [auth A] MOL2 format, chain R [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain P [auth A] mmCIF format, chain R [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain P [auth A]	P [auth A], Q [auth A], R [auth A]	SILVER ION Ag FOIXSVOLVBLSDH-UHFFFAOYSA-N		Interactions Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Interactions & Density Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A]
CU Query on CU Download:Ideal Coordinates CCD File SDF format, chain V [auth A] SDF format, chain U [auth A] SDF format, chain T [auth A] SDF format, chain S [auth A] MOL2 format, chain V [auth A] MOL2 format, chain U [auth A] MOL2 format, chain T [auth A] MOL2 format, chain S [auth A] mmCIF format, chain V [auth A] mmCIF format, chain U [auth A] mmCIF format, chain T [auth A] mmCIF format, chain S [auth A]	S [auth A], T [auth A], U [auth A], V [auth A]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Interactions & Density Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A]
OH Query on OH Download:Ideal Coordinates CCD File SDF format, chain W [auth A] MOL2 format, chain W [auth A] mmCIF format, chain W [auth A]	W [auth A]	HYDROXIDE ION H O XLYOFNOQVPJJNP-UHFFFAOYSA-M		Interactions Focus chain W [auth A] Interactions & Density Focus chain W [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.19 Å
R-Value Free: 0.194 (Depositor), 0.194 (DCC)
R-Value Work: 0.146 (Depositor), 0.147 (DCC)
R-Value Observed: 0.148 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 93.706	α = 90
b = 110.579	β = 90
c = 96.547	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
SCALA	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-02-17

Deposition Author(s):

Jimenez-Arroyo, N.

Rudino-Pinera, E.

Revision History (Full details and data files)

Version 1.0: 2016-02-17
Type: Initial release
Version 1.1: 2024-01-10
Changes: Data collection, Database references, Derived calculations, Other, Refinement description
