4YKE | pdb_00004yke

Crystal structure of eukaryotic Mre11 catalytic domain from Chaetomium thermophilum

• PDB DOI: https://doi.org/10.2210/pdb4YKE/pdb

• Classification: HYDROLASE
• Organism(s): Thermochaetoides thermophila DSM 1495
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2015-03-04 Released: 2015-06-03
• Deposition Author(s): Seifert, F.U., Lammens, K., Hopfner, K.-P.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.78 Å
• R-Value Free:
  0.231 (Depositor), 0.218 (DCC)
• R-Value Work:
  0.198 (Depositor), 0.199 (DCC)
• R-Value Observed:
  0.202 (Depositor)

Starting Model: experimental

Literature

Structure of the catalytic domain of Mre11 from Chaetomium thermophilum.

Seifert, F.U., Lammens, K., Hopfner, K.P.

(2015) Acta Crystallogr F Struct Biol Commun 71: 752-757

• PubMed: 26057807
• DOI: https://doi.org/10.1107/S2053230X15007566
• Primary Citation Related Structures:
  4YKE


• PubMed Abstract:


  Together with the Rad50 ATPase, the Mre11 nuclease forms an evolutionarily conserved protein complex that plays a central role in the repair of DNA double-strand breaks (DSBs). Mre11-Rad50 detects and processes DNA ends, and has functions in the tethering as well as the signalling of DSBs. The Mre11 dimer can bind one or two DNA ends or hairpins, and processes DNA endonucleolytically as well as exonucleolytically in the 3'-to-5' direction. Here, the crystal structure of the Mre11 catalytic domain dimer from Chaetomium thermophilum (CtMre11(CD)) is reported. CtMre11(CD) crystals diffracted to 2.8 Å resolution and revealed previously undefined features within the dimer interface, in particular fully ordered eukaryote-specific insertion loops that considerably expand the dimer interface. Furthermore, comparison with other eukaryotic Mre11 structures reveals differences in the conformations of the dimer and the capping domain. In summary, the results reported here provide new insights into the architecture of the eukaryotic Mre11 dimer.

---

Organizational Affiliation:
• Gene Center and Department of Biochemistry, Ludwig-Maximilians-University Munich, Feodor-Lynen-Strasse 25, 81377 Munich, Germany.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 126.19 kDa
• Atom Count: 6,612
• Modeled Residue Count: 809
• Deposited Residue Count: 1,096
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mre11	A, B	548	Thermochaetoides thermophila DSM 1495	Mutation(s): 0  Gene Names: CTHT_0007600 EC: 3.1
UniProt
Find proteins for G0RYR3 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719)) Explore G0RYR3  Go to UniProtKB:  G0RYR3

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MN	C [auth A], D [auth A], E [auth B], F [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.78 Å
• R-Value Free:  0.231 (Depositor), 0.218 (DCC)
• R-Value Work:  0.198 (Depositor), 0.199 (DCC)
• R-Value Observed: 0.202 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.722	α = 90
b = 56.555	β = 90
c = 304.562	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
PHASER	phasing
Coot	model building
XDS	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2015-06-03
Deposition Author(s): Seifert, F.U., Lammens, K., Hopfner, K.-P.

Revision History

• Version 1.0: 2015-06-03
  Type: Initial release

• Version 1.1: 2015-06-17
  Changes: Database references
• Version 1.2: 2024-01-10
  Changes: Data collection, Database references, Derived calculations, Refinement description
