4WAJ | pdb_00004waj

H. influenzae beta-carbonic anhydase variant P48S/A49P


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:
    0.232 (Depositor), 0.203 (DCC)
  • R-Value Work:
    0.161 (Depositor)
  • R-Value Observed:
    0.164 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4WAJ

This is version 1.5 of the entry. See complete history

Literature

Allosteric Reversion of Haemophilus influenzae beta-Carbonic Anhydrase via a Proline Shift.

Hoffmann, K.M.Million-Perez, H.R.Merkhofer, R.Nicholson, H.Rowlett, R.S.

(2015) Biochemistry 54: 598-611

  • DOI: https://doi.org/10.1021/bi501116e
  • Primary Citation Related Structures:
    4WAJ, 4WAK, 4WAM

  • PubMed Abstract:

    Haemophilus influenzae β-carbonic anhydrase (HICA) has been reverse-engineered in the allosteric site region to resemble the nonallosteric Pisum sativum enzyme in order to identify critical features of allostery and intersusbunit communication. Three variants (W39V/G41A, P48S/A49P, and W39V/G41A/P48S/A49P) were identified, through a comparison with a crystal structure of nonallosteric P. sativum β-carbonic anhydrase (PSCA, PDB 1EKJ ), to potentially revert HICA to a nonallosteric enzyme. The W39V/G41A and P48S/A49P mutations decreased the apparent kcat/Km proton dependence from 4 to 2 and 1, respectively, increasing the overall maximal kcat/Km to 16 ± 2 μM(-1) s(-1) (380% of wild type) and 17 ± 3 μM(-1) s(-1) (405% of wild type). The pKa values of the metal-bound water molecule based on the pH-rate profile kinetics (8.32 ± 0.04 for W39V/G41A and 8.3 ± 0.1 for P48S/A49P) were also slightly higher than that for the wild-type enzyme (7.74 ± 0.04). The P48S/A49P variant has lost all pH-rate cooperativity. The W39V/G41A/P48S/A49P variant's kinetics were unusual and were fit with a log-linear function with a slope 0.9 ± 0.2. The crystal structure of the W39V/G41A variant revealed an active site very similar to the T-state wild-type oligomer with bicarbonate trapped in the escort site. By contrast, the X-ray crystal structure of a proline shift variant (P48S/A49P) reveals that it has adopted an active site conformation nearly identical to that of nonallosteric β-carbonic anhydrase (R-state) for one chain, including a tight association with the dimer-exchanged N-terminal helices; the second chain in the asymmetric unit is associated in a biologically relevant oligomer, but it adopts a T-state conformation that is not capped by dimer-exchanged N-terminal helices. The hybrid R/T nature of HICA P48S/A49P structurally recapitulates the interruption of pH-rate cooperativity observed for this variant. Comparison of the conformations of the R and T chains of P48S/A49P suggests a new hypothesis to explain HICA allosteric communication that is mediated by the N-terminal helices and anion binding at the dimer interface.


  • Organizational Affiliation
    • Department of Chemistry, Gonzaga University , 502 East Boone Avenue, Spokane, Washington 99258, United States.

Macromolecule Content

  • Total Structure Weight: 53.12 kDa
  • Atom Count: 3,307
  • Modeled Residue Count: 400
  • Deposited Residue Count: 458
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Carbonic anhydrase 2
A, B
229Haemophilus influenzae Rd KW20Mutation(s): 2
Gene Names: canHI_1301
EC: 4.2.1.1
UniProt
Find proteins for P45148 (Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd))
Explore P45148
Go to UniProtKB:  P45148
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP45148
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:  0.232 (Depositor), 0.203 (DCC)
  • R-Value Work:  0.161 (Depositor)
  • R-Value Observed: 0.164 (Depositor)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 82.777α = 90
b = 82.777β = 90
c = 186.496γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PHASERphasing
Cootmodel building

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, United States)United StatesMCB-1157332

Revision History  (Full details and data files)

  • Version 1.0: 2014-12-31
    Type: Initial release
  • Version 1.1: 2015-01-14
    Changes: Database references
  • Version 1.2: 2015-01-28
    Changes: Database references
  • Version 1.3: 2017-09-13
    Changes: Author supporting evidence, Database references, Derived calculations, Other, Source and taxonomy, Structure summary
  • Version 1.4: 2019-11-27
    Changes: Author supporting evidence
  • Version 1.5: 2023-09-27
    Changes: Data collection, Database references, Refinement description
