4W1U | pdb_00004w1u

Crystal structure of Rv3557c/KstR2, a transcriptional repressor involved in cholesterol metabolism in Mycobacterium tuberculosis

PDB DOI: https://doi.org/10.2210/pdb4W1U/pdb

Classification: TRANSCRIPTION
Organism(s): Mycobacterium tuberculosis H37Rv
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2014-08-13 Released: 2015-07-29
Deposition Author(s): Dawes, S.S., Kendall, S.K., Baker, E.N., Lott, J.S.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.88 Å
R-Value Free:
0.200 (Depositor), 0.199 (DCC)
R-Value Work:
0.172 (Depositor), 0.174 (DCC)
R-Value Observed:
0.173 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4W1U

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of Rv3557c/KstR2, a transcriptional repressor involved in cholesterol metabolism in Mycobacterium tuberculosis.

Dawes, S.S., Kendall, S.K., Baker, E.N., Lott, J.S.

To be published.

Macromolecule Content

Total Structure Weight: 23.25 kDa
Atom Count: 1,748
Modeled Residue Count: 193
Deposited Residue Count: 204
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
HTH-type transcriptional repressor KstR2	A	204	Mycobacterium tuberculosis H37Rv	Mutation(s): 0 Gene Names: kstR2, Rv3557c
UniProt
Find proteins for P9WMB9 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WMB9 Go to UniProtKB: P9WMB9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P9WMB9
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.88 Å
R-Value Free: 0.200 (Depositor), 0.199 (DCC)
R-Value Work: 0.172 (Depositor), 0.174 (DCC)
R-Value Observed: 0.173 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.356	α = 90
b = 90.292	β = 128.21
c = 49.693	γ = 90

Software Package:

Software Name	Purpose
iMOSFLM	data reduction
SCALA	data scaling
ARP	model building
WARP	model building
PDB_EXTRACT	data extraction
PHASER	phasing
PHENIX	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-07-29

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2015-07-29
Type: Initial release
Version 1.1: 2017-11-22
Changes: Derived calculations, Refinement description, Source and taxonomy
Version 1.2: 2023-09-27
Changes: Data collection, Database references, Refinement description
