4TX7

Crystal structure of chitinase (GH19) from Vigna unguiculata


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.173
  • R-Value Work: 0.149
  • R-Value Observed: 0.150

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.6 of the entry. See complete history


Literature

Production in Pichia pastoris, antifungal activity and crystal structure of a class I chitinase from cowpea (Vigna unguiculata): Insights into sugar binding mode and hydrolytic action.

Landim, P.G.Correia, T.O.Silva, F.D.Nepomuceno, D.R.Costa, H.P.Pereira, H.M.Lobo, M.D.Moreno, F.B.Brandao-Neto, J.Medeiros, S.C.Vasconcelos, I.M.Oliveira, J.T.Sousa, B.L.Barroso-Neto, I.L.Freire, V.N.Carvalho, C.P.Monteiro-Moreira, A.C.Grangeiro, T.B.

(2017) Biochimie

  • DOI: https://doi.org/10.1016/j.biochi.2017.01.014
  • Primary Citation of Related Structures:
    4TX7

  • PubMed Abstract:

    A cowpea class I chitinase (VuChiI) was expressed in the methylotrophic yeast P. pastoris. The recombinant protein was secreted into the culture medium and purified by affinity chromatography on a chitin matrix. The purified chitinase migrated on SDS-polyacrylamide gel electrophoresis as two closely-related bands with apparent molecular masses of 34 and 37 kDa. The identity of these bands as VuChiI was demonstrated by mass spectrometry analysis of tryptic peptides and N-terminal amino acid sequencing. The recombinant chitinase was able to hydrolyze colloidal chitin but did not exhibit enzymatic activity toward synthetic substrates. The highest hydrolytic activity of the cowpea chitinase toward colloidal chitin was observed at pH 5.0. Furthermore, most VuChiI activity (approximately 92%) was retained after heating to 50 °C for 30 min, whereas treatment with 5 mM Cu 2+ caused a reduction of 67% in the enzyme's chitinolytic activity. The recombinant protein had antifungal activity as revealed by its ability to inhibit the spore germination and mycelial growth of Penicillium herquei. The three-dimensional structure of VuChiI was resolved at a resolution of 1.55 Å by molecular replacement. The refined model had 245 amino acid residues and 381 water molecules, and the final R-factor and R free values were 14.78 and 17.22%, respectively. The catalytic domain of VuChiI adopts an α-helix-rich fold, stabilized by 3 disulfide bridges and possessing a wide catalytic cleft. Analysis of the crystallographic model and molecular docking calculations using chito-oligosaccharides provided evidences about the VuChiI residues involved in sugar binding and catalysis, and a possible mechanism of antifungal action is suggested.


  • Organizational Affiliation

    Laboratório de Genética Molecular, Departamento de Biologia, Centro de Ciências, Universidade Federal do Ceará, Fortaleza, Ceará, Brazil.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Class I chitinase245Vigna unguiculata subsp. sesquipedalisMutation(s): 2
EC: 3.2.1.14
UniProt
Find proteins for Q9FUH3 (Vigna unguiculata subsp. sesquipedalis)
Explore Q9FUH3
Go to UniProtKB:  Q9FUH3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FUH3
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.173
  • R-Value Work: 0.149
  • R-Value Observed: 0.150
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 69.32α = 90
b = 69.32β = 90
c = 114.87γ = 120
Software Package:
Software NamePurpose
DNAdata collection
XDSdata reduction
PDB_EXTRACTdata extraction
PHASERphasing
PHENIXrefinement
xia2data scaling
GDAdata collection

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Brazilian National Council for Scientific and Technological Development (CNPq)Brazil--
Sao Paulo Research Foundation (FAPESP)Brazil--

Revision History  (Full details and data files)

  • Version 1.0: 2015-10-14
    Type: Initial release
  • Version 1.1: 2017-02-15
    Changes: Database references
  • Version 1.2: 2017-11-22
    Changes: Data collection, Refinement description
  • Version 1.3: 2019-04-17
    Changes: Author supporting evidence, Data collection
  • Version 1.4: 2020-01-01
    Changes: Author supporting evidence
  • Version 1.5: 2023-09-27
    Changes: Data collection, Database references, Refinement description
  • Version 1.6: 2024-10-09
    Changes: Structure summary
