4RUL | pdb_00004rul

Crystal structure of full-length E.Coli topoisomerase I in complex with ssDNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.259 (Depositor), 0.262 (DCC)
  • R-Value Work:
    0.209 (Depositor), 0.214 (DCC)
  • R-Value Observed:
    0.212 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4RUL

This is version 1.2 of the entry. See complete history

Literature

Structural basis for suppression of hypernegative DNA supercoiling by E. coli topoisomerase I.

Tan, K.Zhou, Q.Cheng, B.Zhang, Z.Joachimiak, A.Tse-Dinh, Y.C.

(2015) Nucleic Acids Res 43: 11031-11046

  • DOI: https://doi.org/10.1093/nar/gkv1073
  • Primary Citation Related Structures:
    4RUL

  • PubMed Abstract:

    Escherichia coli topoisomerase I has an essential function in preventing hypernegative supercoiling of DNA. A full length structure of E. coli topoisomerase I reported here shows how the C-terminal domains bind single-stranded DNA (ssDNA) to recognize the accumulation of negative supercoils in duplex DNA. These C-terminal domains of E. coli topoisomerase I are known to interact with RNA polymerase, and two flexible linkers within the C-terminal domains may assist in the movement of the ssDNA for the rapid removal of transcription driven negative supercoils. The structure has also unveiled for the first time how the 4-Cys zinc ribbon domain and zinc ribbon-like domain bind ssDNA with primarily π-stacking interactions. This novel structure, in combination with new biochemical data, provides important insights into the mechanism of genome regulation by type IA topoisomerases that is essential for life, as well as the structures of homologous type IA TOP3α and TOP3β from higher eukaryotes that also have multiple 4-Cys zinc ribbon domains required for their physiological functions.


  • Organizational Affiliation
    • Structural Biology Center, Biosciences, Argonne National Laboratory, 9700 S. Cass Avenue, Argonne, IL 60439, USA ktan@anl.gov.

Macromolecule Content

  • Total Structure Weight: 107.37 kDa
  • Atom Count: 6,480
  • Modeled Residue Count: 836
  • Deposited Residue Count: 896
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA topoisomerase 1867Escherichia coli DH1Mutation(s): 0
Gene Names: ECDH1ME8569_1213EcDH1_2375ESCHERICHIA COLItopA
EC: 5.99.1.2 (PDB Primary Data), 5.6.2.1 (UniProt)
UniProt
Find proteins for P06612 (Escherichia coli (strain K12))
Explore P06612
Go to UniProtKB:  P06612
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06612
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 2
MoleculeChains LengthOrganismImage
single strand DNA29synthetic construct
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4

Query on SO4



Download:Ideal Coordinates CCD File
G [auth A],
H [auth A],
I [auth A],
J [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL

Query on GOL



Download:Ideal Coordinates CCD File
K [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A],
F [auth A]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.259 (Depositor), 0.262 (DCC)
  • R-Value Work:  0.209 (Depositor), 0.214 (DCC)
  • R-Value Observed: 0.212 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.613α = 90
b = 80.295β = 91.26
c = 97.475γ = 90
Software Package:
Software NamePurpose
SBC-Collectdata collection
HKL-3000data reduction
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
HKL-3000phasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-11-04
    Type: Initial release
  • Version 1.1: 2016-01-06
    Changes: Database references
  • Version 1.2: 2023-09-20
    Changes: Data collection, Database references, Derived calculations, Refinement description
