4QQB | pdb_00004qqb

Structural basis for the assembly of the SXL-UNR translation regulatory complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:
    0.236 (Depositor), 0.239 (DCC)
  • R-Value Work:
    0.198 (Depositor), 0.202 (DCC)
  • R-Value Observed:
    0.200 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4QQB

This is version 1.4 of the entry. See complete history

Literature

Structural basis for the assembly of the Sxl-Unr translation regulatory complex.

Hennig, J.Militti, C.Popowicz, G.M.Wang, I.Sonntag, M.Geerlof, A.Gabel, F.Gebauer, F.Sattler, M.

(2014) Nature 515: 287-290

  • DOI: https://doi.org/10.1038/nature13693
  • Primary Citation Related Structures:
    4QQB

  • PubMed Abstract:

    Genetic equality between males and females is established by chromosome-wide dosage-compensation mechanisms. In the fruitfly Drosophila melanogaster, the dosage-compensation complex promotes twofold hypertranscription of the single male X-chromosome and is silenced in females by inhibition of the translation of msl2, which codes for the limiting component of the dosage-compensation complex. The female-specific protein Sex-lethal (Sxl) recruits Upstream-of-N-ras (Unr) to the 3' untranslated region of msl2 messenger RNA, preventing the engagement of the small ribosomal subunit. Here we report the 2.8 Å crystal structure, NMR and small-angle X-ray and neutron scattering data of the ternary Sxl-Unr-msl2 ribonucleoprotein complex featuring unprecedented intertwined interactions of two Sxl RNA recognition motifs, a Unr cold-shock domain and RNA. Cooperative complex formation is associated with a 1,000-fold increase of RNA binding affinity for the Unr cold-shock domain and involves novel ternary interactions, as well as non-canonical RNA contacts by the α1 helix of Sxl RNA recognition motif 1. Our results suggest that repression of dosage compensation, necessary for female viability, is triggered by specific, cooperative molecular interactions that lock a ribonucleoprotein switch to regulate translation. The structure serves as a paradigm for how a combination of general and widespread RNA binding domains expands the code for specific single-stranded RNA recognition in the regulation of gene expression.


  • Organizational Affiliation
    • 1] Institute of Structural Biology, Helmholtz Zentrum München, Ingolstädter Landstrasse 1, DE-85764, Germany [2] Center for Integrated Protein Science Munich at Biomolecular NMR Spectroscopy, Department Chemie, Technische Universität München, Lichtenbergstr. 4, DE-85747 Garching, Germany.

Macromolecule Content

  • Total Structure Weight: 67.43 kDa
  • Atom Count: 4,556
  • Modeled Residue Count: 516
  • Deposited Residue Count: 532
  • Unique protein chains: 2
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Protein sex-lethalB [auth A],
D [auth B]
176Drosophila melanogasterMutation(s): 0
Gene Names: SxlSx1CG43770
UniProt
Find proteins for P19339 (Drosophila melanogaster)
Explore P19339
Go to UniProtKB:  P19339
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP19339
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Upstream of N-ras, isoform AE [auth X],
F [auth Y]
72Drosophila melanogasterMutation(s): 0
Gene Names: UnrCG7015Dmel_CG7015
UniProt
Find proteins for B7Z0E2 (Drosophila melanogaster)
Explore B7Z0E2
Go to UniProtKB:  B7Z0E2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7Z0E2
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
msl2 mRNAA [auth P],
C
18N/A
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:  0.236 (Depositor), 0.239 (DCC)
  • R-Value Work:  0.198 (Depositor), 0.202 (DCC)
  • R-Value Observed: 0.200 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 94.36α = 90
b = 110.97β = 90
c = 139.15γ = 90
Software Package:
Software NamePurpose
MAR345data collection
PHASERphasing
REFMACrefinement
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-09-03
    Type: Initial release
  • Version 1.1: 2014-09-24
    Changes: Database references
  • Version 1.2: 2014-11-26
    Changes: Database references
  • Version 1.3: 2017-11-22
    Changes: Refinement description
  • Version 1.4: 2023-09-20
    Changes: Data collection, Database references, Refinement description
