4PDM

Crystal Structure of K+ selective NaK mutant in rubidium

  • Classification: TRANSPORT PROTEIN
  • Organism(s): Bacillus cereus ATCC 14579
  • Expression System: Escherichia coli
  • Mutation(s): Yes
  • Membrane Protein: Yes  PDBTMMemProtMD

  • Deposited: 2014-04-19 Released: 2014-07-09
  • Deposition Author(s): Lam, Y.
  • Funding Organization(s): Howard Hughes Medical Institute (HHMI), National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), Welch Foundation

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.58 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.204
  • R-Value Observed: 0.206

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history.


Literature

High Resolution Structural Views of Rubidium, Cesium and Barium Binding within a Potassium Selective Channel Filter

Lam, Y., Zeng, W., Sauer, D.B., Jiang, Y.

To be published.

Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Potassium channel protein
A, B
97Bacillus cereus ATCC 14579Mutation(s): 2
Gene Names: BC_0669
Membrane Entity: Yes
UniProt
Find proteins for Q81HW2 (Bacillus cereus (strain ATCC 14579 / DSM 31 / CCUG 7414 / JCM 2152 / NBRC 15305 / NCIMB 9373 / NCTC 2599 / NRRL B-3711))
Explore Q81HW2
Go to UniProtKB:  Q81HW2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ81HW2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MPD
Query on MPD
Download Ideal Coordinates CCD File
F [auth A],
J [auth B],
K [auth B]		(4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
RB
Query on RB
Download Ideal Coordinates CCD File
C [auth A]
D [auth A]
E [auth A]
G [auth B]
H [auth B]
C [auth A],
D [auth A],
E [auth A],
G [auth B],
H [auth B],
I [auth B]
RUBIDIUM ION
Rb
NCCSSGKUIKYAJD-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.58 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.204
  • R-Value Observed: 0.206
  • Space Group: I 4
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 68.011α = 90
b = 68.011β = 90
c = 89.346γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

  • Released Date: 2014-07-09
    • Deposition Author(s): Lam, Y.
Funding OrganizationLocationGrant Number
Howard Hughes Medical Institute (HHMI)United States--
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM079179
Welch FoundationUnited StatesGrant I-1578

Revision History  (Full details and data files)

  • Version 1.0: 2014-07-09
    Type: Initial release
  • Version 1.1: 2017-09-27
    Changes: Author supporting evidence, Database references, Derived calculations, Other, Source and taxonomy
  • Version 1.2: 2019-11-20
    Changes: Author supporting evidence
  • Version 1.3: 2023-09-27
    Changes: Data collection, Database references, Derived calculations, Refinement description
