4OTE | pdb_00004ote

Crystal structure of a putative lipoprotein (CD630_1653) from Clostridium difficile 630 at 2.20 A resolution

PDB DOI: https://doi.org/10.2210/pdb4OTE/pdb

Classification: PROTEIN TRANSPORT
Organism(s): Clostridioides difficile 630
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2014-02-13 Released: 2014-03-19
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.240 (Depositor), 0.250 (DCC)
R-Value Work:
0.197 (Depositor), 0.208 (DCC)
R-Value Observed:
0.199 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of a putative lipoprotein (CD630_1653) from Clostridium difficile 630 at 2.20 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 55.37 kDa
Atom Count: 3,999
Modeled Residue Count: 478
Deposited Residue Count: 482
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lipoprotein	A, B	241	Clostridioides difficile 630	Mutation(s): 0 Gene Names: CD630_16530
UniProt
Find proteins for Q186K7 (Clostridioides difficile (strain 630)) Explore Q186K7 Go to UniProtKB: Q186K7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q186K7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MSE Query on MSE Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain U [auth B] MOL2 format, chain C [auth A] MOL2 format, chain U [auth B] mmCIF format, chain C [auth A] mmCIF format, chain U [auth B]	C [auth A], U [auth B]	SELENOMETHIONINE C₅ H₁₁ N O₂ Se RJFAYQIBOAGBLC-BYPYZUCNSA-N		Interactions Focus chain C [auth A] Focus chain U [auth B] Interactions & Density Focus chain C [auth A] Focus chain U [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain FA [auth B] MOL2 format, chain FA [auth B] mmCIF format, chain FA [auth B]	FA [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain FA [auth B] Interactions & Density Focus chain FA [auth B]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth B] D [auth A] E [auth A] F [auth A] G [auth A] AA [auth B], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain AA [auth B] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain DA [auth B] SDF format, chain EA [auth B] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain S [auth A] SDF format, chain T [auth A] MOL2 format, chain DA [auth B] MOL2 format, chain EA [auth B] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] MOL2 format, chain T [auth A] mmCIF format, chain DA [auth B] mmCIF format, chain EA [auth B] mmCIF format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain S [auth A] mmCIF format, chain T [auth A]	DA [auth B] EA [auth B] Q [auth A] R [auth A] S [auth A] DA [auth B], EA [auth B], Q [auth A], R [auth A], S [auth A], T [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain DA [auth B] Focus chain EA [auth B] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Interactions & Density Focus chain DA [auth B] Focus chain EA [auth B] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain BA [auth B] SDF format, chain CA [auth B] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] MOL2 format, chain BA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] mmCIF format, chain BA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A]	BA [auth B] CA [auth B] M [auth A] N [auth A] O [auth A] BA [auth B], CA [auth B], M [auth A], N [auth A], O [auth A], P [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain BA [auth B] Focus chain CA [auth B] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Interactions & Density Focus chain BA [auth B] Focus chain CA [auth B] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free: 0.240 (Depositor), 0.250 (DCC)
R-Value Work: 0.197 (Depositor), 0.208 (DCC)
R-Value Observed: 0.199 (Depositor)

Diffraction Data:

Space Group: P 2₁ 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 120.508	α = 90
b = 120.508	β = 90
c = 120.508	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
SCALA	data scaling
REFMAC	refinement
MOSFLM	data reduction
SHELXD	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-03-19

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2014-03-19
Type: Initial release
Version 1.1: 2014-03-26
Changes: Other
Version 1.2: 2017-11-22
Changes: Refinement description
Version 1.3: 2018-01-24
Changes: Database references
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2024-11-27
Changes: Data collection, Refinement description, Structure summary
