4O4W | pdb_00004o4w

Crystal Structure of Trichomonas vaginalis Triosephosphate Isomerase Ile45-Gly mutant (Tvag_497370)

PDB DOI: https://doi.org/10.2210/pdb4O4W/pdb

Classification: ISOMERASE
Organism(s): Trichomonas vaginalis
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2013-12-19 Released: 2014-12-24
Deposition Author(s): Lara-Gonzalez, S., Benitez-Cardoza, C.G., Brieba, L.G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free:
0.232 (Depositor), 0.230 (DCC)
R-Value Work:
0.194 (Depositor), 0.193 (DCC)
R-Value Observed:
0.196 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4O4W

This is version 1.2 of the entry. See complete history.

Literature

Engineering mutants with altered dimer-monomer equilibrium reveal the existence of stable monomeric Triosephosphate isomerases

Lara-Gonzalez, S., Benitez-Cardoza, C.G., Brieba, L.G.

To be published.

Macromolecule Content

Total Structure Weight: 27.49 kDa
Atom Count: 1,902
Modeled Residue Count: 250
Deposited Residue Count: 252
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Triosephosphate isomerase	A	252	Trichomonas vaginalis	Mutation(s): 1 Gene Names: TVAG_497370 EC: 5.3.1.1
UniProt
Find proteins for A2EGX9 (Trichomonas vaginalis (strain ATCC PRA-98 / G3)) Explore A2EGX9 Go to UniProtKB: A2EGX9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A2EGX9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free: 0.232 (Depositor), 0.230 (DCC)
R-Value Work: 0.194 (Depositor), 0.193 (DCC)
R-Value Observed: 0.196 (Depositor)

Space Group: P 2 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.782	α = 90
b = 56.01	β = 90
c = 104.754	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-12-24

Deposition Author(s):

Lara-Gonzalez, S.

Benitez-Cardoza, C.G.

Revision History (Full details and data files)

Version 1.0: 2014-12-24
Type: Initial release
Version 1.1: 2018-03-07
Changes: Data collection
Version 1.2: 2024-02-28
Changes: Data collection, Database references, Derived calculations
