4NZH | pdb_00004nzh

A. fumigatus flavin-dependent ornithine monooxygenase R279A mutant

PDB DOI: https://doi.org/10.2210/pdb4NZH/pdb

Classification: OXIDOREDUCTASE
Organism(s): Aspergillus fumigatus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2013-12-12 Released: 2015-03-04
Deposition Author(s): Robinson, R., Franceschini, S., Sobrado, P.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.243 (Depositor), 0.242 (DCC)
R-Value Work:
0.206 (Depositor), 0.205 (DCC)
R-Value Observed:
0.208 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4NZH

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

A. fumigatus flavin-dependent ornithine monooxygenase R279A mutant

Robinson, R., Franceschini, S., Sobrado, P.

To be published.

Macromolecule Content

Total Structure Weight: 58.16 kDa
Atom Count: 3,812
Modeled Residue Count: 448
Deposited Residue Count: 501
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
L-ornithine N5 monooxygenase	A	501	Aspergillus fumigatus	Mutation(s): 1 Gene Names: sidA EC: 1.14.13.196
UniProt
Find proteins for E9QYP0 (Aspergillus fumigatus (strain ATCC MYA-4609 / CBS 101355 / FGSC A1100 / Af293)) Explore E9QYP0 Go to UniProtKB: E9QYP0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	E9QYP0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FAD Query on FAD Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	FLAVIN-ADENINE DINUCLEOTIDE C₂₇ H₃₃ N₉ O₁₅ P₂ VWWQXMAJTJZDQX-UYBVJOGSSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
ORN Query on ORN Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	L-ornithine C₅ H₁₂ N₂ O₂ AHLPHDHHMVZTML-BYPYZUCNSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A], F [auth A], G [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.243 (Depositor), 0.242 (DCC)
R-Value Work: 0.206 (Depositor), 0.205 (DCC)
R-Value Observed: 0.208 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 77.905	α = 90
b = 84.083	β = 90
c = 144.902	γ = 90

Software Package:

Software Name	Purpose
PHASER	phasing
REFMAC	refinement
HKL-2000	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-03-04

Deposition Author(s):

Franceschini, S.

Revision History (Full details and data files)

Version 1.0: 2015-03-04
Type: Initial release
Version 1.1: 2024-02-28
Changes: Data collection, Database references, Derived calculations
