4LEN | pdb_00004len

CTX-M-9 in complex with the broad spectrum inhibitor 3-(2- carboxyvinyl)benzo(b)thiophene-2-boronic acid


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free:
    0.182 (Depositor), 0.180 (DCC)
  • R-Value Work:
    0.159 (Depositor), 0.159 (DCC)
  • R-Value Observed:
    0.160 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4LEN

Ligand Structure Quality Assessment


This is version 1.5 of the entry. See complete history

Literature

Targeting Class A and C Serine beta-Lactamases with a Broad-Spectrum Boronic Acid Derivative.

Tondi, D.Venturelli, A.Bonnet, R.Pozzi, C.Shoichet, B.K.Costi, M.P.

(2014) J Med Chem 57: 5449-5458

  • DOI: https://doi.org/10.1021/jm5006572
  • Primary Citation Related Structures:
    4LEN

  • PubMed Abstract:

    Production of β-lactamases (BLs) is the most widespread resistance mechanism adopted by bacteria to fight β-lactam antibiotics. The substrate spectrum of BLs has become increasingly broad, posing a serious health problem. Thus, there is an urgent need for novel BL inhibitors. Boronic acid transition-state analogues are able to reverse the resistance conferred by class A and C BLs. We describe a boronic acid analogue possessing interesting and potent broad-spectrum activity vs class A and C serine-based BLs. Starting from benzo(b)thiophene-2-boronic acid (BZBTH2B), a nanomolar non-β-lactam inhibitor of AmpC that can potentiate the activity of a third-generation cephalosporin against AmpC-producing resistant bacteria, we designed a novel broad-spectrum nanomolar inhibitor of class A and C BLs. Structure-based drug design (SBDD), synthesis, enzymology data, and X-ray crystallography results are discussed. We clarified the inhibitor binding geometry responsible for broad-spectrum activity vs serine-active BLs using double mutant thermodynamic cycle studies.


  • Organizational Affiliation
    • Department of Pharmaceutical Chemistry, University of California San Francisco , 600 16th Street San Francisco, California 94143-2240, United States.

Macromolecule Content

  • Total Structure Weight: 56.44 kDa
  • Atom Count: 4,802
  • Modeled Residue Count: 524
  • Deposited Residue Count: 526
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-lactamase
A, B
263Escherichia coliMutation(s): 0
Gene Names: blaCTX-M-9blaCTX-M-9ablaCTX-M-9a blaCTX-M-9 blaCTX-M-9bblaCTX-M-9b
EC: 3.5.2.6
UniProt
Find proteins for Q9L5C8 (Escherichia coli)
Explore Q9L5C8
Go to UniProtKB:  Q9L5C8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9L5C8
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
2GK

Query on 2GK



Download:Ideal Coordinates CCD File
C [auth A],
D [auth B]
(2E)-3-[2-(dihydroxyboranyl)-1-benzothiophen-3-yl]prop-2-enoic acid
C11 H9 B O4 S
IYRVQPJBSDCZBO-AATRIKPKSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free:  0.182 (Depositor), 0.180 (DCC)
  • R-Value Work:  0.159 (Depositor), 0.159 (DCC)
  • R-Value Observed: 0.160 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.116α = 90
b = 106.595β = 102.03
c = 47.68γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
CNSrefinement
HKL-2000data reduction
SCALEPACKdata scaling
CNSphasing
HKL-2000data collection

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

  • Released Date: 2014-06-18
  • Deposition Author(s): Tondi, D.

Revision History  (Full details and data files)

  • Version 1.0: 2014-06-18
    Type: Initial release
  • Version 1.1: 2014-07-16
    Changes: Database references
  • Version 1.2: 2016-10-19
    Changes: Structure summary
  • Version 1.3: 2019-07-17
    Changes: Data collection, Derived calculations, Refinement description
  • Version 1.4: 2023-09-20
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.5: 2024-10-16
    Changes: Structure summary
