4KOE | pdb_00004koe

Quinolone(Trovafloxacin)-DNA cleavage complex of type IV topoisomerase from S. pneumoniae

PDB DOI: https://doi.org/10.2210/pdb4KOE/pdb
NAKB: 4KOE

Classification: ISOMERASE/DNA/INHIBITOR
Organism(s): Streptococcus pneumoniae TIGR4
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2013-05-11 Released: 2014-11-26
Deposition Author(s): Laponogov, I., Pan, X.-S., Veselkov, D.A., Fisher, L.M., Sanderson, M.R.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.02 Å
R-Value Free:
0.210 (Depositor), 0.207 (DCC)
R-Value Work:
0.175 (Depositor), 0.172 (DCC)
R-Value Observed:
0.177 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Inhibitor-stabilised cleavage complexes of topoisomerase IIa: structural analysis of drug-dependent inter- and intramolecular interactions

Laponogov, I., Pan, X.-S., Veselkov, D.A., Fisher, L.M., Sanderson, M.R.

To be published.

Macromolecule Content

Total Structure Weight: 185.66 kDa
Atom Count: 11,105
Modeled Residue Count: 1,415
Deposited Residue Count: 1,564
Unique protein chains: 2
Unique nucleic acid chains: 4

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA topoisomerase 4 subunit A	A, B	496	Streptococcus pneumoniae TIGR4	Mutation(s): 1 Gene Names: parC, SP_0855 EC: 5.99.1.3 (PDB Primary Data), 5.6.2.2 (UniProt)
UniProt
Find proteins for P72525 (Streptococcus pneumoniae serotype 4 (strain ATCC BAA-334 / TIGR4)) Explore P72525 Go to UniProtKB: P72525
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P72525
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA topoisomerase 4 subunit B	C, D	268	Streptococcus pneumoniae TIGR4	Mutation(s): 2 Gene Names: parE EC: 5.99.1.3 (PDB Primary Data), 5.6.2.2 (UniProt)
UniProt
Find proteins for Q59961 (Streptococcus pneumoniae serotype 4 (strain ATCC BAA-334 / TIGR4)) Explore Q59961 Go to UniProtKB: Q59961
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q59961
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 3
Molecule	Chains	Length	Organism	Image
E-site DNA1	E	7	N/A
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 4
Molecule	Chains	Length	Organism	Image
E-site DNA2	F	11	N/A
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 5
Molecule	Chains	Length	Organism	Image
E-site DNA3	G	7	N/A
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 6
Molecule	Chains	Length	Organism	Image
E-site DNA4	H	11	N/A
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TR6 Query on TR6 Download Ideal Coordinates CCD File SDF format, chain P [auth H] SDF format, chain O [auth F] MOL2 format, chain P [auth H] MOL2 format, chain O [auth F] mmCIF format, chain P [auth H] mmCIF format, chain O [auth F]	O [auth F], P [auth H]	Trovafloxacin C₂₀ H₁₅ F₃ N₄ O₃ WVPSKSLAZQPAKQ-CDMJZVDBSA-N		Interactions Focus chain O [auth F] Focus chain P [auth H] Interactions & Density Focus chain O [auth F] Focus chain P [auth H]
MG Query on MG Download Ideal Coordinates CCD File SDF format, chain N [auth D] SDF format, chain M [auth C] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth A] SDF format, chain I [auth A] MOL2 format, chain N [auth D] MOL2 format, chain M [auth C] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] mmCIF format, chain N [auth D] mmCIF format, chain M [auth C] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A]	I [auth A] J [auth A] K [auth B] L [auth B] M [auth C] I [auth A], J [auth A], K [auth B], L [auth B], M [auth C], N [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth C] Focus chain N [auth D] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth C] Focus chain N [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.02 Å
R-Value Free: 0.210 (Depositor), 0.207 (DCC)
R-Value Work: 0.175 (Depositor), 0.172 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 158.04	α = 90
b = 158.04	β = 90
c = 210.42	γ = 120

Software Package:

Software Name	Purpose
GDE	data collection
PHASER	phasing
PHENIX	refinement
xia2	data reduction
XDS	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2014-11-26

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2014-11-26
Type: Initial release
Version 1.1: 2017-11-15
Changes: Refinement description
Version 1.2: 2024-11-06
Changes: Data collection, Database references, Derived calculations, Structure summary
