4KDR | pdb_00004kdr

Crystal Structure of UBIG/SAH complex

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.233 (Depositor), 0.234 (DCC)
  • R-Value Work:
    0.189 (Depositor), 0.190 (DCC)
  • R-Value Observed:
    0.191 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4KDR

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history.

Literature

Crystal Structure of the UBIG/SAH complex

Zhu, Y., Teng, M., Li, X.

To be published.

Macromolecule Content

  • Total Structure Weight: 25.22 kDa
  • Atom Count: 1,660
  • Modeled Residue Count: 208
  • Deposited Residue Count: 223
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:
|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
3-demethylubiquinone-9 3-methyltransferase223Escherichia coli K-12Mutation(s): 0
Gene Names: ubiG, pufX, yfaB, b2232, JW2226
EC: 2.1.1.64 (PDB Primary Data), 2.1.1.222 (PDB Primary Data)
UniProt
Find proteins for P17993 (Escherichia coli (strain K12))
Explore P17993
Go to UniProtKB:  P17993
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP17993
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SAH

Query on SAH


Download:Ideal Coordinates CCD File
B [auth A]S-ADENOSYL-L-HOMOCYSTEINE
C14 H20 N6 O5 S
ZJUKTBDSGOFHSH-WFMPWKQPSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.233 (Depositor), 0.234 (DCC)
  • R-Value Work:  0.189 (Depositor), 0.190 (DCC)
  • R-Value Observed: 0.191 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 141.133α = 90
b = 39.5β = 94.4
c = 40.422γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
MOLREPphasing
REFMACrefinement
HKL-2000data reduction
SCALAdata scaling
HKL-2000data collection

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-04-30
    Type: Initial release
  • Version 1.1: 2017-08-16
    Changes: Refinement description, Source and taxonomy
  • Version 1.2: 2019-07-17
    Changes: Data collection, Refinement description
  • Version 1.3: 2024-02-28
    Changes: Data collection, Database references, Derived calculations
