4JRK | pdb_00004jrk

Crystal Structure of Escherichia coli Hfq Surface Mutant


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.89 Å
  • R-Value Free:
    0.216 (Depositor), 0.220 (DCC)
  • R-Value Work:
    0.177 (Depositor), 0.178 (DCC)
  • R-Value Observed:
    0.179 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4JRK

This is version 1.3 of the entry. See complete history

Literature

Mapping Hfq-RNA interaction surfaces using tryptophan fluorescence quenching.

Robinson, K.E.Orans, J.Kovach, A.R.Link, T.M.Brennan, R.G.

(2014) Nucleic Acids Res 42: 2736-2749

  • DOI: https://doi.org/10.1093/nar/gkt1171
  • Primary Citation Related Structures:
    4JLI, 4JRI, 4JRK, 4JUV

  • PubMed Abstract:

    Hfq is a posttranscriptional riboregulator and RNA chaperone that binds small RNAs and target mRNAs to effect their annealing and message-specific regulation in response to environmental stressors. Structures of Hfq-RNA complexes indicate that U-rich sequences prefer the proximal face and A-rich sequences the distal face; however, the Hfq-binding sites of most RNAs are unknown. Here, we present an Hfq-RNA mapping approach that uses single tryptophan-substituted Hfq proteins, all of which retain the wild-type Hfq structure, and tryptophan fluorescence quenching (TFQ) by proximal RNA binding. TFQ properly identified the respective distal and proximal binding of A15 and U6 RNA to Gram-negative Escherichia coli (Ec) Hfq and the distal face binding of (AA)3A, (AU)3A and (AC)3A to Gram-positive Staphylococcus aureus (Sa) Hfq. The inability of (GU)3G to bind the distal face of Sa Hfq reveals the (R-L)n binding motif is a more restrictive (A-L)n binding motif. Remarkably Hfq from Gram-positive Listeria monocytogenes (Lm) binds (GU)3G on its proximal face. TFQ experiments also revealed the Ec Hfq (A-R-N)n distal face-binding motif should be redefined as an (A-A-N)n binding motif. TFQ data also demonstrated that the 5'-untranslated region of hfq mRNA binds both the proximal and distal faces of Ec Hfq and the unstructured C-terminus.


  • Organizational Affiliation
    • Department of Biochemistry, Duke University, Durham, NC 27710, USA and Department of Biochemistry and Molecular Biology, University of Texas MD Anderson Cancer Center, Houston, TX 77030, USA.

Macromolecule Content

  • Total Structure Weight: 23.02 kDa
  • Atom Count: 1,815
  • Modeled Residue Count: 192
  • Deposited Residue Count: 204
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Protein hfq
A, B, C
68Escherichia coli K-12Mutation(s): 1
Gene Names: hfqb4172JW4130
UniProt
Find proteins for P0A6X3 (Escherichia coli (strain K12))
Explore P0A6X3
Go to UniProtKB:  P0A6X3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A6X3
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.89 Å
  • R-Value Free:  0.216 (Depositor), 0.220 (DCC)
  • R-Value Work:  0.177 (Depositor), 0.178 (DCC)
  • R-Value Observed: 0.179 (Depositor)
Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 33.41α = 90
b = 66.309β = 90
c = 85.106γ = 90
Software Package:
Software NamePurpose
HKL-3000data collection
CCP4model building
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
CCP4phasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-12-11
    Type: Initial release
  • Version 1.1: 2014-03-12
    Changes: Database references
  • Version 1.2: 2017-11-15
    Changes: Refinement description
  • Version 1.3: 2024-02-28
    Changes: Data collection, Database references
