4JAC | pdb_00004jac

Dehaloperoxidase-Hemoglobin T56S


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.93 Å
  • R-Value Free:
    0.243 (Depositor), 0.243 (DCC)
  • R-Value Work:
    0.182 (Depositor), 0.184 (DCC)
  • R-Value Observed:
    0.185 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4JAC

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

The role of T56 in controlling the flexibility of the distal histidine in dehaloperoxidase-hemoglobin from Amphitrite ornata.

Jiang, S.Wright, I.Swartz, P.Franzen, S.

(2013) Biochim Biophys Acta 1834: 2020-2029

  • DOI: https://doi.org/10.1016/j.bbapap.2013.06.005
  • Primary Citation Related Structures:
    4JAC

  • PubMed Abstract:

    The activation of dehaloperoxidase-hemoglobin (DHP) to form a ferryl intermediate requires the distal histidine, H55, to act as an acid base catalyst. The lack of ancillary amino acids in the distal pocket to assist in this process makes H55 even more important to the formation of active intermediates than in conventional peroxidases. Therefore, one can infer that the precise conformation H55 may greatly affect the enzymatic activity. Using site-direct mutagenesis at position T56, immediately adjacent to H55, we have confirmed that subtle changes in the conformation of H55 affect the catalytic efficiency of DHP. Mutating T56 to a smaller amino acid appears to permit H55 to rotate with relatively low barriers between conformations in the distal pocket, which may lead to an increase in catalytic activity. On the other hand, larger amino acids in the neighboring site appear to restrict the rotation of H55 due to the steric hindrance. In the case of T56V, which is an isosteric mutation, H55 appears less mobile, but forced to be closer to the heme iron than in wild type. Both proximity to the heme iron and flexibility of motion in some of the mutants can result in an increased catalytic rate, but can also lead to protein inactivation due to ligation of H55 to the heme iron, which is known as hemichrome formation. A balance of enzymatic rate and protein stability with respect to hemichrome formation appears to be optimum in wild type DHP (WT-DHP).


  • Organizational Affiliation
    • Department of Chemistry, North Carolina State University, Raleigh, NC 27695, USA.

Macromolecule Content

  • Total Structure Weight: 32.92 kDa
  • Atom Count: 2,650
  • Modeled Residue Count: 274
  • Deposited Residue Count: 276
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Dehaloperoxidase A
A, B
138Amphitrite ornataMutation(s): 1
UniProt
Find proteins for Q9NAV8 (Amphitrite ornata)
Explore Q9NAV8
Go to UniProtKB:  Q9NAV8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NAV8
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
HEM

Query on HEM



Download:Ideal Coordinates CCD File
C [auth A],
H [auth B]
PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
SO4

Query on SO4



Download:Ideal Coordinates CCD File
D [auth A],
E [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
AZI

Query on AZI



Download:Ideal Coordinates CCD File
F [auth A],
G [auth A],
I [auth B],
J [auth B]
AZIDE ION
N3
IVRMZWNICZWHMI-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.93 Å
  • R-Value Free:  0.243 (Depositor), 0.243 (DCC)
  • R-Value Work:  0.182 (Depositor), 0.184 (DCC)
  • R-Value Observed: 0.185 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 57.453α = 90
b = 67.503β = 90
c = 68.925γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
PHENIXmodel building
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-11-27
    Type: Initial release
  • Version 1.1: 2024-02-28
    Changes: Data collection, Database references, Derived calculations
