4IYJ | pdb_00004iyj

Crystal structure of a putative acylhydrolase (BACUNI_03406) from Bacteroides uniformis ATCC 8492 at 1.37 A resolution

PDB DOI: https://doi.org/10.2210/pdb4IYJ/pdb

Classification: HYDROLASE
Organism(s): Bacteroides uniformis ATCC 8492
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2013-01-28 Released: 2013-03-06
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.37 Å
R-Value Free:
0.173 (Depositor), 0.181 (DCC)
R-Value Work:
0.134 (Depositor), 0.147 (DCC)
R-Value Observed:
0.136 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4IYJ

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of a putative acylhydrolase (BACUNI_03406) from Bacteroides uniformis ATCC 8492 at 1.37 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 47.8 kDa
Atom Count: 4,119
Modeled Residue Count: 419
Deposited Residue Count: 424
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GDSL-like protein	A, B	212	Bacteroides uniformis ATCC 8492	Mutation(s): 0

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain G [auth B] SDF format, chain D [auth A] MOL2 format, chain G [auth B] MOL2 format, chain D [auth A] mmCIF format, chain G [auth B] mmCIF format, chain D [auth A]	D [auth A], G [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain G [auth B] Interactions & Density Focus chain D [auth A] Focus chain G [auth B]
UNL Query on UNL Download:Ideal Coordinates CCD File	C [auth A], F [auth B]	Unknown ligand VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain F [auth B] Interactions & Density Focus chain C [auth A] Focus chain F [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.37 Å
R-Value Free: 0.173 (Depositor), 0.181 (DCC)
R-Value Work: 0.134 (Depositor), 0.147 (DCC)
R-Value Observed: 0.136 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.899	α = 90
b = 61.282	β = 90
c = 124.514	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
SCALA	data scaling
REFMAC	refinement
MOSFLM	data reduction
SHELXD	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-03-06

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2013-03-06
Type: Initial release
Version 1.1: 2017-11-15
Changes: Refinement description
Version 1.2: 2023-02-01
Changes: Database references, Derived calculations
Version 1.3: 2024-11-06
Changes: Data collection, Structure summary
