4HAO | pdb_00004hao

Crystal Structure of Inorganic Polyphosphate/ATP-NAD Kinase from Yersinia pestis CO92

PDB DOI: https://doi.org/10.2210/pdb4HAO/pdb

Classification: TRANSFERASE
Organism(s): Yersinia pestis CO92
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2012-09-27 Released: 2012-10-10
Deposition Author(s): Kim, Y., Maltseva, N., Jedrzejczak, R., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.55 Å
R-Value Free:
0.241 (Depositor), 0.246 (DCC)
R-Value Work:
0.185 (Depositor), 0.189 (DCC)
R-Value Observed:
0.188 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of Inorganic Polyphosphate/ATP-NAD Kinase from Yersinia pestis CO92

Kim, Y., Maltseva, N., Jedrzejczak, R., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 68.72 kDa
Atom Count: 4,553
Modeled Residue Count: 567
Deposited Residue Count: 608
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable inorganic polyphosphate/ATP-NAD kinase	A, B	304	Yersinia pestis CO92	Mutation(s): 0 Gene Names: ppnK, y3074, YPO1106, YP_1050 EC: 2.7.1.23
UniProt
Find proteins for Q8ZH09 (Yersinia pestis) Explore Q8ZH09 Go to UniProtKB: Q8ZH09
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8ZH09
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain N [auth B] SDF format, chain F [auth A] MOL2 format, chain N [auth B] MOL2 format, chain F [auth A] mmCIF format, chain N [auth B] mmCIF format, chain F [auth A]	F [auth A], N [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth A] Focus chain N [auth B] Interactions & Density Focus chain F [auth A] Focus chain N [auth B]
ACY Query on ACY Download:Ideal Coordinates CCD File SDF format, chain O [auth B] SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain G [auth B] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain O [auth B] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain G [auth B] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain O [auth B] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain G [auth B] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth A] G [auth B] H [auth B] C [auth A], D [auth A], E [auth A], G [auth B], H [auth B], I [auth B], J [auth B], K [auth B], L [auth B], M [auth B], O [auth B]	ACETIC ACID C₂ H₄ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain O [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain O [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.55 Å
R-Value Free: 0.241 (Depositor), 0.246 (DCC)
R-Value Work: 0.185 (Depositor), 0.189 (DCC)
R-Value Observed: 0.188 (Depositor)

Diffraction Data:

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 138.091	α = 90
b = 65.16	β = 124.95
c = 86.386	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	data collection
HKL-3000	phasing
MOLREP	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-10-10

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2012-10-10
Type: Initial release
Version 1.1: 2023-09-20
Changes: Data collection, Database references, Derived calculations, Refinement description
